- PROSOFT MVI69E-MBTCP is a Modbus TCP/IP communication module specifically designed for Rockwell Automation ControlLogix programmable automation controller (PAC). Here is a detailed introduction of it:
Core function
Modbus TCP/IP Communication
Supports the Modbus TCP/IP protocol, allowing connection to up to 20 third-party devices that support this protocol, enabling communication with various types of devices.
Provides up to 5000 Modbus slave station addresses of 16-bit registers, meeting the requirements for large-scale data exchange.
High-speed Data Transmission
The module adopts a compact design, making it easy to install in the ControlLogix PAC, supporting high-speed data transmission, and enhancing the system response speed.
Supports Enron and Daniel style floating-point data implementation, suitable for SCADA and field device interface applications.
Flexible Communication Control
Supports client and server connections, using the Modbus protocol to communicate with various devices for interfaces.
The module’s functions can be enabled/disabled through ladder logic, facilitating configuration and control of communication.
Technical Specifications
Hardware Parameters
Dimensions: Standard size of ControlLogix series modules, compact design saves space.
Power Supply: Power consumption is 500 milliamps at 5 volt DC, ensuring stable operation.
Environmental Adaptability:
Operating Temperature: 0°C to 60°C.
Relative Humidity: 5% to 95% (no condensation), suitable for harsh industrial environments.
Interfaces:
1 Ethernet port for diagnostic and application data transmission.
Supports 1769 I/O bus function, compatible with CompactLogix processors version 16 and higher (does not support MicroLogix 1500).
LED Indicators and Status Monitoring
LED Indicators: Provide indicators for module status, backplane activity, Ethernet port activity, and configuration activity, facilitating real-time monitoring of module operation status.
Status Monitoring: Supports integration of CompactLogix system diagnostic data, providing logical definitions through processor controller labels, improving system diagnostic capabilities.
ProSoft Wireless Protocol
ProSoft Wireless Protocol (PWP) offers versatility where a mix of control devices requires cooperation with each other. This involves sharing of information across the applications regardless of device or network type, often at high speed, and with high reliability. Wireless bandwidth utilization is optimized by using efficient communication methods. The protocol supports Unicast, Broadcast and Multicast group messaging. Efficiency is based on the fact each device on the “wireless” network can produce these types of messages and each device determines which of these messages to consume.
General Specifications – Radio Modules
These modules utilize a full function wireless network card, supporting RF data rates up to 11 Mbps. The modules function as a client, providing an ultra-fast wireless solution for the most demanding industrial applications.
These modules allow you to connect various field devices using different networks or protocols and share data between these devices “over-the-air.” This is accomplished by exchanging shared common database information over-the-air with ProSoft Technology’s efficient but powerful wireless protocol.
