PROSOFT RLX2-IHNF-E is based on Ethernet/IP or Modbus

The PROSOFT RLX2-IHNF-E is an industrial communication module designed for EtherNet/IP to PROFIBUS DP Master/Slave conversion, enabling seamless integration between Allen-Bradley PLCs (via EtherNet/IP) and PROFIBUS DP networks. Below are key details about its features, applications, and specifications:

Key Features

Dual-Protocol Support
- Acts as a gateway between EtherNet/IP (used by Rockwell Automation/Allen-Bradley PLCs) and PROFIBUS DP (a widely used fieldbus protocol in Europe).
- Supports both Master and Slave configurations for PROFIBUS DP, allowing flexibility in connecting to PROFIBUS devices or controllers.
High Performance
- Designed for real-time industrial automation with low latency.
- Supports high-speed data exchange (up to 12 Mbps for PROFIBUS DP).
Configuration & Diagnostics
- Configurable via ProSoft Configuration Builder software (or Rockwell Studio 5000 Logix Designer).
- Built-in diagnostics for troubleshooting network issues.
Redundancy Support
- Some models may support redundant EtherNet/IP networks for high availability.
Industrial-Grade Design
- Robust metal housing for harsh environments (temperature, vibration, EMI resistance).
- DIN-rail mountable for easy installation in control panels.

Applications

Connecting PROFIBUS DP devices (e.g., drives, sensors, actuators) to Allen-Bradley PLCs (CompactLogix, ControlLogix).
Migrating legacy PROFIBUS systems to modern EtherNet/IP networks without replacing existing devices.
Industrial automation in sectors like automotive, oil & gas, water treatment, and manufacturing.

Technical Specifications

Feature	Details
Protocols	EtherNet/IP (Master/Slave), PROFIBUS DP (Master/Slave)
Network Speed	PROFIBUS DP: Up to 12 Mbps; EtherNet/IP: 10/100 Mbps (Auto-negotiating)
Power Supply	24 VDC (typically)
LED Indicators	Status, network activity, errors
Certifications	CE, UL, cUL, ATEX (if applicable for hazardous areas)
Environmental Rating	IP20 (standard); some models may offer higher protection
