Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | CLC-V02.3C-FW |
| Manufacturer | REXROTH |
| Product Type | Control Module for Proportional Valves |
| Input Voltage | 24V DC ±10% |
| Control Signal | ±10V DC / 4-20mA |
| Output Current | 0-3A (adjustable) |
| Communication Interface | CANopen, RS-232 |
| Response Time | <5 ms |
| Diagnostics | LED status indicators, error codes |
| Operating Temperature | -20°C to +60°C |
| Protection Rating | IP65 |
| Dimensions | 120 x 80 x 40 mm |
Main Features and Advantages
The Rexroth CLC-V02.3C-FW delivers precision control for proportional valves in demanding hydraulic systems. With its advanced current regulation technology, this module provides exceptional valve positioning accuracy while maintaining smooth operation across its full 0-3A output range. The dual-input capability (±10V DC and 4-20mA) ensures compatibility with various control systems.
Intelligent diagnostics: Integrated status LEDs and comprehensive error detection provide real-time monitoring of valve performance and system health. The CLC-V02.3C-FW features adaptive current control that automatically compensates for coil temperature variations, maintaining consistent valve response throughout extended operation periods.
Robust industrial design: Encased in an IP65-rated housing, the module withstands harsh industrial environments including dust, moisture, and vibration. The operating temperature range of -20°C to +60°C ensures reliable performance in both extreme cold and hot conditions.
Seamless integration: With native CANopen and RS-232 communication interfaces, the CLC-V02.3C-FW integrates effortlessly into modern automation architectures. The compact form factor enables flexible mounting in space-constrained control cabinets.
Our hydraulic control specialists provide configuration support – contact us via WhatsApp for valve matching and system integration guidance.
Application Areas
The CLC-V02.3C-FW excels in industrial hydraulic systems including injection molding machines, metal forming presses, test benches, and mobile equipment. Its precise control capabilities make it ideal for applications requiring accurate flow or pressure regulation such as plastic extrusion lines, hydraulic presses, and material handling systems.
Related Products
- CLC-V01.1C-FW: Compact version for smaller valve applications
- 4WRPEH: Rexroth proportional valves compatible with CLC series
- VT-VRPA: Integrated proportional valves with built-in electronics
