REXROTH PPC-R22.1N-T-NN-P2-NN-FW VM11 Industrial Panel PC

Overview

The Rexroth PPC-R22.1N-T-NN-P2-NN-FW VM11 is a high-performance Industrial Panel PC designed for demanding automation and control applications. Part of Bosch Rexroth’s IndraControl V series, this unit combines a robust 22.1-inch TFT display with a powerful computing platform, enabling seamless integration into Rexroth’s IndraMotion motion control systems and other industrial environments. It serves as a centralized HMI (Human-Machine Interface) and control unit for machinery requiring precise visualization, data processing, and real-time communication.

Key Features & Benefits

• Large High-Resolution Display: 22.1-inch TFT LCD with LED backlight and wide viewing angles, providing clear visualization of complex processes and diagnostics.

• Rugged Industrial Design: Built to withstand harsh conditions (IP65-rated front panel, resistant to vibrations, shocks, and temperature extremes).

• Powerful Processing: Equipped with Intel® Core™ i7 or similar high-performance processors (varies by configuration) for handling complex control algorithms and data logging.

• Multi-Port Connectivity: Features extensive I/O including Ethernet (Gigabit), USB, RS-232/485, and optional fieldbus interfaces (PROFIBUS, PROFINET, EtherCAT) for seamless integration with PLCs, drives, and I/O modules.

• Integrated Safety: Supports safety functions (e.g., Safe Operating Stop) when used with Rexroth’s IndraMotion safety controllers.

• Pre-Installed Software: Often includes Rexroth’s IndraWorks engineering suite for simplified configuration and programming.

Technical Specifications

Parameter Specification
Manufacturer Part Number PPC-R22.1N-T-NN-P2-NN-FW VM11
Series Rexroth IndraControl V
Display Size & Type 22.1″ TFT LCD (LED backlight)
Resolution 1920 x 1080 (Full HD)
Touchscreen Projected capacitive (multi-touch)
Processor Intel® Core™ i7 (exact model varies; confirm with datasheet)
Memory 8 GB DDR4 RAM (expandable)
Storage SSD (e.g., 256 GB, configurable)
I/O Ports 2x Gigabit Ethernet, 4x USB, 1x RS-232/485, optional fieldbus cards
Protection Rating IP65 (front panel), IP20 (rear)
Operating Temperature 0°C to 50°C (with derating)
Power Supply 24 VDC (typical industrial voltage)
Certifications CE, UL, cULus, compliant with ISO 13849 for safety

Typical Applications

• Motion Control Systems: Serves as the HMI for Rexroth IndraMotion CNC and PLC-based automation in machine tools.

• Factory Automation: Central control unit for assembly lines, robotics, and material handling systems.

• Energy & Heavy Machinery: Monitoring and control of hydraulic systems, turbines, and test benches.

• Packaging & Printing: Visualization and parameterization for high-speed packaging machinery.

• Automotive Manufacturing: Integration into production lines for real-time data display and control.
