S-093H 3BHB009885R0004 Phase module

The ABB S-093H 3BHB030478R0309 is a phase module designed for medium voltage inverters.It is a phase module of the three-phase voltage source inverter (VSI) topology and can be used as an AC-DC or DC-AC converter.Self-commutating, 6-pulse, three-phase voltage source inverter using IGCT technology.

Product size: length85(cm)*width55(cm)*height65(cm)

Product weight: 190KG

Shipping size: 100(l cm)*70(w cm)*90(h cm)

Shipping weight:222KG

Key Specifications

Brand: ABB

Product Type: Phase Module

Model Number: S-093H 3BHB030478R0309

Voltage Rating: Medium Voltage

Functionality: DC-AC/AC-DC conversion.

Features:

Anti-electromagnetic, can operate normally in electromagnetic environment
Using IGCT technology self-commutation, improve efficiency, reduce loss
Durability, IP54 protection for safe use in harsh environments.

Application of ABB S-093H 3BHB030478R0309 PHASE MODULE in medium voltage frequency conversion system..png

Application of ABB S-093H 3BHB030478R0309 PHASE MODULE in medium voltage frequency conversion system.

5SHY3545L0003

Phase ABB S-093H 3BHB030478R0309

Phase S-073N 3BHB009884R0021 Power Electronic Building Block (PEBB),

ACS 6000 ABB ACS 6000 System Integration
