T8100 Trustworthy TMR Controller Cabinet

The Trusted@TMR expansion processor module is located in the Trusted processor slot of the Expander chassis and provides the “from” interface between the Expander bus and the Expander chassis bottom.
Board. The expansion bus enables the use of multiple chassis systems to achieve unshielded twisted-pair (UTP) cable connections while maintaining fault tolerance and high bandwidth (MB – Inter-Module Bus) functionality. Modules are for expansion.
The display bus, the module itself and the expander provide a fault-protected chassis, ensuring that the impact of these potential failures is localized and maximizing system availability. This module features the HIFT TMR architecture’s capability.
Fault-free operation. Comprehensive diagnosis, monitoring and testing provide rapid fault identification. Hot standby, module backup support configuration, allowing for automatic and manual repair strategies.
Characteristics:
Triple module redundancy (TMR), fault-tolerant (3-2-0) operation.
Hardware-based Fault Tolerance (HIFT) architecture.
The dedicated hardware and software testing system provides extremely fast fault identification and response time.
Automatic fault handling, no nuisance alarms.
Thermal replacement.
The front panel indicator lights show the operating status and condition of the module.

Key Features of  T8100：

• Trusted Operating System: Ensures secure and reliable operation.
• Dual Ethernet and Four Serial Ports: Offers versatile connectivity options.
• Support for Multiple Communication Protocols: Including Modbus RTU, Open Modbus TCP, Trusted Peer to Peer, Trusted Enhanced Peer to Peer, ICS2000, CP2000, among others.
• Modbus Slave Functionality: With optional Modbus Master capability when used with the T812X Trusted Processor Interface Adapter.
• Sequence Of Events (SOE) Over Modbus: Optional feature for detailed event logging.
• Front Panel Serial Diagnostic Port: Along with fault and status indicators for easy troubleshooting.
• Power Supply: Operates on a backplane supply of 20 Vdc to 32 Vdc.
• Isolation: Provides electrical isolation between various components for safety and reliability.
• Operating Conditions: Designed to operate within temperatures ranging from 0°C to +60°C (+32°F to +140°F). ICS T8151B
