The Model 3805H module has been modified to support increased inductive loads. It is fully compatible for use in all applications of the 3805E module. The Model 3806E and Model 3807  modules are optimized for turbomachinery control.

The Model 3806E High Current AO  Module has two 20 to 320 mA outputs to drive servo actuators. The Model 3807 BiPolar AO Module has four -60 to + 60 mA outputs to drive servo coils in servo-control applications. The termination panel for Model 3807 contains four hard-wired coil diagnostic inputs. The Model 3807  is designed for control applications only, and should not be used in safety applications.

Triplicated temperature transducers residing on the field termination panel support cold-junction compensation.  Each channel of a Thermocouple Input  Module performs auto-calibration using internal precision voltage references. On the isolated module, a  faulting cold-junction transducer is annunciated by a cold-junction indicator on the front panel.
