Product Overview
The TRICONEX 9771-210 is a redundant power supply module designed for Triconex Tricon v11 safety instrumented systems (SIS), providing critical power distribution and fault tolerance for mission-critical industrial processes. As part of Schneider Electric’s Triconex safety platform, this module ensures continuous operation in high-risk environments by integrating dual AC/DC power inputs with automatic load balancing. The TRICONEX 9771-210 supports hot-swappable replacement without interrupting system operations, making it indispensable for oil refineries, nuclear plants, and chemical processing facilities. Its galvanic isolation and surge protection mechanisms meet IEC 61508 SIL 3 standards, ensuring immunity to electromagnetic interference and voltage spikes.
Engineered for maximum reliability, the TRICONEX 9771-210 features real-time diagnostics with LED status indicators for voltage, current, and fault conditions. The module’s dual-redundant design allows seamless failover between power sources, maintaining system integrity even during grid fluctuations. Compatible with Tricon v9 through v11 controllers, it provides 5V DC and 24V DC outputs with ±0.5% voltage regulation precision. The TRICONEX 9771-210 is certified for use in Class I Division 2 hazardous areas, with a robust aluminum housing that dissipates heat efficiently in ambient temperatures up to 70°C.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 9771-210 |
| Manufacturer | TRICONEX (Schneider Electric) |
| Product Type | Redundant Power Supply Module |
| Input Voltage | 100-240V AC (50/60 Hz) ±15% |
| Output Voltage | 5V DC (30A), 24V DC (5A) |
| Efficiency | 92% @ Full Load |
| Redundancy | Dual Active/Hot Standby |
| Isolation Voltage | 1500V AC (Input to Output) |
| Operating Temperature | -40°C to +70°C |
| Certifications | IEC 61508 SIL 3, ATEX, UL Class I Div 2 |
| MTBF | 500,000 Hours |
| Dimensions | 200 x 130 x 60 mm (H x W x D) |
Advanced diagnostics:
Integrated health monitoring includes real-time reporting of output ripple (<50mV p-p) and current derating alerts. The module’s fault-tolerant design triggers audible alarms and relays status codes to the Tricon controller via dedicated safety buses.
Safety compliance:
Meets NFPA 85 boiler safety standards and API 670 machinery protection requirements. The TRICONEX 9771-210 includes arc-resistant terminals and reinforced creepage distances (>8mm) for operation in corrosive atmospheres.
Application Areas
The TRICONEX 9771-210 is critical in offshore drilling platforms for emergency shutdown (ESD) systems, where power stability ensures safe valve actuation during blowout scenarios. In LNG terminals, it supports fire and gas detection systems by maintaining uninterrupted power to flame detectors. Key applications include:
- Turbine overspeed protection in power generation
- Burner management systems for furnace safety
- Pipeline leak detection and isolation
- Reactor cooling pump control in chemical plants
- Railway signaling system backups
Its rugged design is ideal for Arctic oil fields (-40°C operations) and coastal refineries exposed to salt spray, complying with NORSOK M-501 corrosion standards.
