Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | VT-TSPD-1-1XV00 R900208591 |
| Manufacturer | Rexroth |
| Product Type | Proportional Directional Control Valve |
| Nominal Size | NG10 |
| Max Operating Pressure | 315 bar |
| Max Flow Rate | 80 L/min |
| Control Signal | ±10V DC / 4-20mA |
| Spool Configuration | 4-way, 3-position |
| Hysteresis | <1% |
| Response Time | 30 ms |
| Operating Temperature | -20°C to +80°C |
| Protection Class | IP65 |
Main Features and Advantages
The Rexroth VT-TSPD-1-1XV00 R900208591 proportional valve delivers precision flow control for demanding hydraulic applications. With its 4-way/3-position spool design and ±10V DC/4-20mA control options, it provides exceptional directional accuracy and smooth operation across its full 80 L/min flow range.
High-performance characteristics: Featuring <1% hysteresis and 30ms response time, the VT-TSPD-1-1XV00 R900208591 maintains precise control even under rapidly changing load conditions. Its pressure-compensated design ensures consistent flow regardless of pressure fluctuations.
Robust industrial construction: Built to withstand harsh environments, this valve operates reliably across -20°C to +80°C temperature ranges and carries IP65 protection against dust and water ingress. The NG10 nominal size makes it ideal for compact hydraulic systems requiring high power density.
Our hydraulic specialists provide free application engineering support – contact us via WhatsApp for configuration assistance and system integration guidance.
Application Areas
The VT-TSPD-1-1XV00 R900208591 excels in precision hydraulic control applications including injection molding machines, metal forming presses, mobile hydraulics, and industrial automation systems. Its responsive control makes it particularly valuable in applications requiring accurate speed and position control of hydraulic cylinders and motors.
Related Products
- VT-VSPD-2-1X: Higher flow version for larger hydraulic systems
- VT-VRPD-1-1X: Pressure control variant for pressure regulation applications
- VT-VRPA-1-511: Compact proportional valve with integrated electronics
