Description
Woodhead SST-PB3-PCU-2 Profibus Card Universal PCI Bus
The SST-PB3-PCI-2 is the next-generation ProfiBus PCI card. It can perform the following functions:
• Act as a DP master
• Act as a DP slave
• Send and receive FDL (layer 2) messages
• Support Master Class 1 and Master Class 2 messaging
• Support simultaneous operation in all of the above modes
• Support the standard ProfiBus baud rates of 9.6K, 19.2K, 31.25K, 45.45K, 93.75K, 187.5K, 500K, 1.5M, 3M, 6M and 12M baud
The card requires both 3.3V and 5V to be supplied by the motherboard. Because 3.3V supply voltage is optional in PCI revision 2.1, the SST-PB3-PCI-2 may not function in some PCI 2.1-compliant motherboards.
The card will auto-detect the motherboard PCI I/O signaling level and adjust its signaling level accordingly, allowing it to function in PCI systems that support either 5V or 3.3V I/O signaling levels.
