XVME-653 VMEbus Pentium Processor Module

Product Description

The XVME-653 is a powerful VMEbus PC compatible processor module from Xycom Automation, the pioneer and leader in VMEbus PC technology. This powerful single-slot VMEbus processor integrates a 233 MHz MMX Pentium CPU with a PCI-to-VMEbus interface and allows users to take advantage of the powerful multiprocessing capability of the VMEbus while utilizing standard off-the-shelf PC software and operating systems.
At the core of the XVME-653 module is the Intel 233MHz MMX CPU combined with 512K of synchronous Level 2 pipeline cache and up to 256 MB of fast-page or EDO DRAM.
The module contains a wide breadth of I/O including PCI Graphics, EIDE and Ethernet controllers, one Universal Serial Bus (USB) Port, two high-speed serial ports, one EPP/ECP parallel port, and PS/2 style keyboard and mouse ports. Further I/O expansion is available using Xycom Automation’s modular I/O carrier modules (XVME-976), which provide a mechanism to expand your system using PMC, PC/ 104, short ISA or PCI modules.
The XVME-653 module is an unbeatable solution for power and I/O on a single-slot VMEbus module.

lf you need to inquire or purchase ,please send the product models to my email or call medirectly .

The XVME-653 features a high-performance, highly integrated Intel chipset that incorporates a host-toPCI bus interface and PCI-to-ISA bridge with Universal Serial Bus host controller.
Display Support
Graphics support is provided by a highly integrated SVGA controller with an internal 2 MB 83 MHz SDRAM frame buffer. Resolutions of up to 1280 × 1024 with 256 colors are supported. The controller uses a 64-bit internal graphics engine with hardware BitBLT to enhance Windows GUI performance. SVGA output is available at the module front panel in standard 15-pin D shell connector.
Network Support
The XVME-653 contains a state-of-the-art Intel 82558 10/100 Mbit Ethernet controller with a 32-bit PCI bus mastering interface to support bus transfers of 100 Mbits per second. The RJ-45 connector on the module’s front panel provides autosensing for 10 BaseT and 100 BaseTX connections.
VMEbus Interface
The PCI-to-VMEbus bridge device provides users with a flexible mapping architecture to allow configurations that will support virtually all user applications.
The bridge device supports multiple VME master and slave images with BLT and DMA capability for highperformance block data operations.
The XVME-653 also contains onboard hardware byte-swapping.
