YOKOGAWA AAI141-H50 S2 ANALOG INPUT MODULE

YOKOGAWA AAI141-H50 S2 ANALOG INPUT MODULE.It Compatible with specific Yokogawa Fieldbus Controllers (FCSs): AFG30, AFG40, AFG8, AFF50, AFV10, AFV30, or AFV40.This module is designed for use in industrial automation systems, particularly for measuring analog input signals from transmitters. It offers flexibility in handling both current and voltage inputs, making it suitable for various process control applications.

Key Features：

Number of input channels: 16, non-isolated

Input signal types:4 to 20 mA DC current input

1 to 5 V DC voltage input

Allowable input current/voltage:Voltage input: ±7.5 V, ±1.3 V common mode

Current input: 25 mA, ±7.5 V

Input resistance:Power ON: 400 Ω to 1000 Ω

Power OFF: 500 kΩ or larger

Accuracy:Voltage input: ±4 mV

Current input: ±16 μA

Data update period: 10 ms

Step response time: 100 ms

Transmitter power supply range: 14.8 V or higher (at 20 mA), 26.4 V or less (at 0 mA)

Maximum current consumption: 310 mA (5 V DC), 450 mA (24 V DC)

Weight:1 kg
