YOKOGAWA AIP830-101 S2 OPERATION KEYBOARD

YOKOGAWA AIP830-101 S2 Operation Keyboard is a rugged industrial HMI interface designed for CENTUM VP and CS 3000 DCS systems. Featuring a durable membrane keypad with tactile feedback and LED indicators, it ensures reliable operation in harsh plant environments. With NEMA 4X/IP65 protection and intuitive layout, it provides efficient process control for critical industrial applications.

Core Specifications

• Model: AIP830-101 S2 (Yokogawa P/N: AIP830-101)

• Compatibility: CENTUM VP/CS 3000 DCS

• Keyboard Type: Industrial membrane switch

• Protection Rating: NEMA 4X/IP65 (dust-tight & water-resistant)

• Operating Temp: -20°C to +60°C

Design & Usability

• Key Layout: 58-key optimized for process control (including function keys)

• Tactile Feedback: Positive-click mechanism (1M+ press life cycle)

• Visual Indicators: 12 LED status lights (red/green)

• Mounting: Panel-mounted with stainless steel bezel

Electrical Characteristics

• Connection: RS-422/485 via 9-pin D-sub connector

• Power Supply: 24V DC (±10%) from DCS

• Current Draw: <100mA (typical)

Durability Features

• Chemical Resistance: Withstands oils/solvents (IEC 60068-2-43)

• Impact Resistance: 50J polycarbonate faceplate

• Vibration Proof: 5-17Hz, 1.5mm amplitude (IEC 60068-2-6)

Functional Capabilities

• Dedicated Keys: Emergency shutdown/acknowledgment buttons

• Custom Labeling: Field-replaceable keycaps

• ESD Protection: ±15kV air/±8kV contact discharge

Certifications

• Safety: UL/cUL 61010-1

• EMC: EN 61326-1 (Industrial immunity)

• Marine: DNV-GL/ABS/Lloyd’s certified

Typical Applications

• Process Control: Oil & gas refineries

• Power Plants: Boiler control systems

• Chemical Plants: Batch process monitoring
