The Yokogawa CP471-00 S1 processor module is a high-performance processor module designed by Yokogawa Electric for the CENTUM VP distributed control system (DCS). It features powerful data processing capabilities, reliable communication performance, and wide application adaptability. Here is a detailed introduction:
I. Core Functions
Efficient Data Processing
Utilizing a 32-bit processor, it offers rapid computing capabilities, ensuring smooth execution of real-time control tasks.
Equipped with 1GB RAM and 16GB flash memory, it supports large-capacity program and data storage, meeting the requirements of complex industrial applications.
Reliable Communication Support
Supports redundant configuration to enhance system reliability, ensuring communication can be maintained even in the event of a single point failure.
Built-in Rich Interfaces, including 16 CAN ports, 16 Ethernet ports, and 12 RS-232/422/485 ports, enabling seamless connection with various devices and systems.
Support for Multiple Signal Types
Supports various signal types such as analog input, digital input, analog output, and digital output, meeting the needs of different control scenarios.
Fault Diagnosis and Warning
Built-in fault diagnosis function, capable of real-time monitoring of system status and early warning of potential issues, improving maintenance efficiency.
Technical Specifications
Processor and Memory
Processor: 32-bit processor, clock frequency not disclosed (some models such as CP471-51 use dual-core ARM Cortex-A57, 2.0 GHz).
Memory: 1GB RAM, 16GB flash memory, supporting efficient storage and access of programs and data.
Interfaces and Communication
Network Interface: Supports Ethernet, Serial, etc. communication protocols to ensure compatibility with various devices.
I/O Expansion: Through dedicated interfaces, I/O modules can be expanded flexibly to adapt to different application scenarios.
Power Supply and Power Consumption
Input Voltage: 12-48VDC, Output Voltage 5VDC, Maximum Output Current 10A, Efficiency greater than 90%.
Power Consumption: Typical power consumption 450mA (5V DC), Specific power consumption varies depending on configuration.
Physical Dimensions and Weight
Size: 170mm × 105mm × 32mm (Some sources show as 16cm × 6cm × 21cm, which may vary due to model or configuration).
Weight: Approximately 120g (Some sources show as 603g or 750g, which may vary due to packaging or accessories).
Environmental Adaptability
Operating Temperature: -20°C to +50°C (Some sources show as 0°C to 60°C, which may vary due to model or configuration).
Storage Temperature: -40°C to +70°C.
Humidity: 5% to 95% relative humidity (no condensation), adaptable to harsh industrial environments.
Application scenarios
Industrial automation control
It is widely applied in industries such as oil and gas, chemical engineering, manufacturing, power, water and wastewater treatment, etc., to achieve monitoring and control of the production process.
Process control
As the core processor module in the CENTUM VP DCS system, it is responsible for data processing, logical control and communication coordination.
Data acquisition and processing
It connects sensors and actuators, and collects and processes real-time on-site data to provide support for decision-making.
