AB80190‑440‑03‑R SMC‑Flex Soft Start Fiber Interface Board Detailed Description
I. Basic Information
Full Material Name: SMC‑Flex Interface PCB Board (SMC‑Flex Soft Start Thyristor Fiber Trigger/Feedback Interface Board)
Applicable Equipment: Allen‑Bradley Bulletin 150‑F Series SMC‑Flex High Power Solid State Soft Starter
Model Disassembly
80190‑440: Board Base Material Number
03: Hardware Version Batch
R: Revision (Revision), can be downward compatible with the same function boards of the previous version, and can be directly replaced on site
Power Supply: The board takes power from the 24VDC control power supply of the soft starter
Core Features: The board arranges multiple fiber transceiver interfaces on the side, serving as an optical isolation bridge between the main control unit and the SCR thyristor power unit
Core Function (The Significance of Fiber Transmission)
Thyristor SCR Trigger Signal Issuance
The conduction triggering instruction of the main control board is sent via fiber to each power thyristor drive board. The fiber is fully electrically isolated, which can isolate the strong electromagnetic interference generated by the on-off of the high-power SCR, avoiding false triggering and tripping of the weak electrical control circuit.
Power Unit Status Collection and Feedback
Through fiber, the gate status of each SCR, thyristor temperature (thermistor), and drive board fault signal are collected to determine whether the power pole is normal in real time.
Fast Fault Locking Protection
Once it detects that the thyristor is overheated, the gate open circuit, or the drive fault, it immediately reports the fault to the main control, and the soft starter immediately stops and locks, reporting Power Pole Fault (Power Pole Failure), preventing the power device from burning out and the motor from being damaged.
Start Self-Check Logic
Before power-on startup, the board checks all fiber links and SCR feedback signals one by one. Only when all self-checks pass, the motor can be started; any abnormality directly prohibits startup and outputs a fault code.
Hardware and Operating Conditions Key Points
Installation Location: Inside the power compartment of the soft starter cabinet, connected to the main control board through flat ribbon cables, and connected to each phase SCR drive unit through multiple fibers
Operating Environment: Applicable to strong electromagnetic and high-temperature control cabinets for starting large power motors such as circulating water pumps, condensers pumps, and fans
Weight approximately 2kg to 3kg, industrial wide-temperature design, strong anti-electromagnetic interference capability
The onboard terminals can output some auxiliary fault contact points, which can be connected to PLC for remote alarm
