Product Description
AB 80190-560-02-R (Allen‑Bradley / Rockwell) is the Analog Control Board (ACB) dedicated for PowerFlex 7000 medium voltage variable frequency drive. The PCB is with conformal coating for moisture, dust and corrosion resistance. As the core signal processing board of PowerFlex7000 drive, it collects analog signals such as motor current and voltage, executes PWM calculation and analog I/O conversion to realize closed-loop vector control of the VFD. It integrates signal conditioning circuits to connect the main drive processor and external analog signal loops. It is an essential spare part for medium voltage VFD cabinets, widely used for maintenance and replacement of high-power motor drive systems in mining, metallurgy and power plants.
Specifications
| Item | Specification |
|---|---|
| Model | 80190-560-02-R |
| Product Type | Medium Voltage VFD Analog Control Board (ACB) |
| Compatible Drive | PowerFlex 7000 Medium Voltage AC Drive |
| PCB Treatment | PCB with conformal coating |
| Core Function | Analog signal acquisition, PWM generation, analog I/O processing |
| Signal | Current & voltage analog signals, PWM pulse signals |
| Mounting | Slot installation inside VFD cabinet |
| Operating Temperature | 0℃ ~ +60℃ |
| Storage Temperature | -40℃ ~ +85℃ |
| Certifications | CE, UL |
| Features | Vibration resistant, conformal coating for harsh industrial environments |
| Country of Origin | USA |
Application
- Metallurgy & mining: PowerFlex7000 medium voltage drive cabinets for high-power motors, control of fans, pumps and crushers.
- Thermal power plants & water treatment: Medium frequency drive systems for large booster pumps and induced draft fans.
- Oil & gas, cement industry: Maintenance and spare parts replacement for medium voltage VFD of large transmission equipment.
- Retrofit of legacy PowerFlex7000 systems, replacement of faulty analog boards to ensure continuous operation of high-power motors.
Related Series Models
- 80190-560-01-R: Older revision analog control board
- 80190-559-02: Compatible replacement version
- 80190-548-01: PowerFlex7000 digital control board
- 80190-571-01: Drive interface board
- 80190-561-01: PowerFlex7000 power supply board
