Product Description
ABB REF615 HBFDACADABC1ABN11G is a feeder protection and control IED within ABB Relion® 615 series, an integrated numerical relay for medium voltage feeders. It adopts withdrawable plug-in hardware design and integrates protection, control, measurement, fault recording and communication functions. It is designed for overhead lines and cable feeders, compatible with both conventional instrument transformers and electronic sensors. It features multi-frequency admittance based earth fault protection, fault location, optional arc flash protection. It supports IEC61850 Ed1/Ed2 including GOOSE, HSR, PRP and IEC61850-9-2LE, and is also compatible with Modbus, DNP3 and IEC60870-5-103 protocols. Equipped with graphical LCD display, it supports local HMI operation and web-based remote HMI access. Widely deployed in distribution substations and industrial MV switchgear for feeder fault protection and substation automation.
Specifications
- Brand: ABB
- Model: REF615 HBFDACADABC1ABN11G
- Product Type: Feeder Protection & Control IED
- Series: Relion® 615 series
- Applicable Voltage: Medium voltage distribution system (3~36kV)
- Protection Functions: Overcurrent, directional overcurrent, sensitive earth fault, high impedance fault detection, voltage/frequency protection, breaker failure protection, fault locator, optional arc flash protection, auto-reclosing
- Measurement: 3-phase voltage, current, power, energy and harmonic measurement
- Communication Protocols: IEC61850 Ed.1/Ed.2, GOOSE, HSR, PRP, IEC61850-9-2LE; Modbus, DNP3, IEC60870-5-103
- Time Synchronization: IEEE1588 V2 precision time sync
- Mechanical Design: Withdrawable plug-in unit for easy maintenance and replacement
- HMI: Graphical color LCD with customizable single line diagram
- Operating Ambient Temperature: -40℃ ~ +70℃
- Protection Class: Front IP40, rear IP20
- Certifications: IEC, CE, UL, KEMA
- Engineering Tool: PCM600 software for parameter setting and fault analysis
Applications
- Utility Power Grid: MV cable & overhead feeder protection for urban substations, ring main units and switching stations
- Industrial Power Distribution: Feeder protection in petrochemical, mining, metallurgy and pulp & paper plants, including distributed generation interconnection protection
- Renewable Energy: Internal distribution line protection and islanding detection for solar PV and wind farms
- Data Centers & Large Buildings: MV switchgear feeder protection for critical loads, fast fault isolation
- Substation Automation: Bay-level IED for digital substations, interfacing with SCADA for telemetry, remote signaling, remote control, fault alarm and disturbance recording
Related Series Models (Relion 615 Series)
- REM615: Motor protection and control relay
- RET615: Transformer protection and control relay
- RED615: Line differential protection relay
- REV615: Capacitor bank protection and control relay
- REG615: Generator and interconnection protection relay
- REU615: Voltage protection and control relay
- RER615: Recloser protection and control relay
- REF615R: 19-inch rack-mounted feeder protection variant
