Product Description
Allen‑Bradley 25B-D013N104 is an AC drive of Rockwell Automation PowerFlex 525 series. It comes with embedded EtherNet/IP communication and safe torque off function. Rated 5.5kW (7.5HP), 3-phase 380~480V AC input, Frame C, IP20 open type without built-in EMC filter. Supports V/F control and sensorless vector control with integrated brake transistor. Compact dimension and easy commissioning, widely used for general motor speed control of fans, pumps and conveyors in automation systems.
Specifications
- Catalog No.: 25B-D013N104
- Series: PowerFlex 525 AC Drive
- Input Voltage: 3-phase AC 380~480V (323–528V)
- Rated Power: 5.5kW (7.5HP), normal duty & heavy duty
- Rated Output Current: 13A
- Frame Size: Frame C
- Protection Class: IP20 (NEMA Open Type)
- Embedded Communication: EtherNet/IP
- Safety Function: Built-in Safe Torque Off
- Filter: No integrated EMC filter
- Control Modes: V/F control, Sensorless Vector Control
- Max Output Frequency: 500Hz
- Braking: Integrated brake transistor
- Mounting: Panel mount / DIN rail mount
- Operating Temperature: -20℃ ~ +60℃ (derate up to 70℃)
- Certifications: CE, UL, cUL, RoHS
Applications
- Material Handling: Belt conveyors, roller tables, elevators
- Fluid Equipment: Water pumps, fans, centrifugal blowers
- Packaging Machinery: Film unwinding, conveyor speed regulation
- Textile Machinery: Spinning, weaving, winding drives
- Woodworking Machines: Cutting and sanding spindle speed control
- General Manufacturing: Production lines, mixing equipment
Similar Models within PowerFlex525 (480V class)
- 25B-D013N104 (This item)
- 25B-D010N104 (4.0kW)
- 25B-D017N104 (7.5kW)
- 25B-D024N104 (11kW)
- 25B-D6P0N104 (2.2kW)
- 25B-D4P0N104 (1.5kW)
- 25B-D2P3N104 (0.75kW)
- 25B-D3P0N104 (1.1kW)
