Product Overview
BE1-25A-A2-F5-V3-D0 is an industrial high-precision diffused silicon pressure sensor belonging to the BE1 series of general-purpose precision pressure detection components. Adopting a standardized modular coding system, the model defines the pressure range, output signal, pressure interface, temperature compensation and accuracy grade through customized suffix codes. It serves as a core detection accessory for industrial automatic fluid pressure monitoring, hydraulic and pneumatic systems, and equipment closed-loop control.
Equipped with an imported diffused silicon sensing core and full-temperature digital compensation algorithm, the sensor features high measurement accuracy, ultra-low temperature drift, excellent stability and strong overload resistance. The fully sealed stainless steel structure is dustproof, waterproof and corrosion-resistant, adapting to complex working conditions of hydraulic, oil & gas and water treatment systems. Supporting 24-hour continuous online monitoring with stable and linear signal output, it is widely used for industrial equipment pressure acquisition, system interlock control and condition monitoring, serving as a universal high-precision model for industrial control system upgrading, replacement and maintenance.
2. Technical Parameters
|
Parameter
|
Specification
|
|
Model Number
|
BE1-25A-A2-F5-V3-D0
|
|
Product Type
|
Diffused Silicon High-precision Pressure Sensor
|
|
Rated Pressure Range
|
25A industrial standard general pressure range
|
|
Signal Output (A2)
|
Standard 4-20mA analog current output
|
|
Pressure Interface (F5)
|
Standard industrial thread interface, universal for hydraulic pipelines
|
|
Temperature Compensation (V3)
|
Full-range high-precision digital temperature compensation, low temperature drift
|
|
Accuracy Grade (D0)
|
High precision grade with ultra-low comprehensive error
|
|
Working Voltage
|
DC 12V～36V wide voltage power supply
|
|
Response Speed
|
Millisecond-level fast response without dynamic lag
|
|
Operating Temperature
|
-20℃～+80℃ industrial wide temperature range
|
|
Protection Grade
|
IP67 full-sealed dustproof and waterproof
|
|
Housing Material
|
304 stainless steel, corrosion-resistant and impact-resistant
|
|
Core Functions
|
Real-time fluid pressure acquisition, signal transmission, closed-loop monitoring, over-limit interlock
|
|
Applicable Systems
|
PLC, DCS, industrial data acquisition system, hydraulic & pneumatic control system
|
3. Product Features
-
High-precision Measurement: Adopts imported diffused silicon sensing core with D0 high-precision calibration and V3 full-temperature compensation, ensuring excellent linearity, high repeatability and minimal comprehensive measurement error under full working conditions.
-
Standard Industrial Signal Output: A2-spec 4-20mA current signal features long transmission distance and strong anti-interference capability, directly compatible with PLC, DCS and various industrial control acquisition devices.
-
Stable Wide-condition Operation: Supports wide temperature operation from -20℃ to +80℃. Built-in temperature compensation algorithm eliminates pressure drift caused by temperature changes, ensuring consistent data stability in all seasons.
-
Industrial-grade Durability: IP67 full-sealed stainless steel structure resists dust, water, oil pollution, corrosion and mechanical impact, adapting to harsh industrial workshop and outdoor environments.
-
Ultra-fast Dynamic Response: Millisecond-level signal response accurately captures instantaneous pressure fluctuations, ideal for dynamic pressure monitoring, equipment frequency conversion regulation and closed-loop pressure control scenarios.
-
Strong Universal Compatibility: F5 standard industrial interface enables simple installation and wiring, compatible with new and old automation equipment for replacement, maintenance and system upgrading projects.
4. Application Scope
BE1-25A-A2-F5-V3-D0 pressure sensor is widely applied in industrial hydraulic and pneumatic systems, mechanical equipment pressure monitoring, automatic production lines, water treatment fluid control systems, oil & gas transmission pressure acquisition, HVAC automatic control, metallurgical and chemical fluid equipment, new energy equipment pressure monitoring, and industrial DCS/PLC data acquisition systems. It performs real-time and precise pressure detection and signal transmission for liquid and gas media, providing accurate and reliable data support for automatic equipment regulation, pressure interlock protection, production data monitoring and equipment fault early warning.
