Bel Fuse CPA200-4530S248G CompactPCI 200W AC-DC Power Module

Bel Fuse CPA200-4530S248G CompactPCI 200W AC-DC Power Module
I. Basic Information
Brand: Bel Fuse (formerly Power-One/Melcher)
Model: CPA200-4530S248G
Product Type: CPCI standard card-type switching power supply (compliant with PICMG CompactPCI industrial bus specification)
Rated Power: 200W
Suffix Explanation: S248G represents the original factory standard air-cooled type, non-coated conventional industrial version, RoHS lead-free compliant, 47-pin standard CPCI connector interface

Electrical Parameters
Input Specifications
AC wide-range input: 90～264VAC, 50/60Hz
Built-in active PFC, power factor ≥ 0.95
Low surge current, soft start design, input surge protection
Four DC outputs (total power 200W)
3.3VDC @ 40A 5VDC @ 40A
+12VDC at 5.5A -12VDC @ 2A
Support single-line current equalization and parallel connection, with N+1 redundant hot backup operation
Includes remote voltage detection compensation function, automatically correcting long-line voltage drop

Core Function Characteristics
Support hot-swappable: CPCI standard plug-and-play design, no downtime for replacing power modules
Redundant power supply: Built-in ORing FET anti-backflow circuit, multiple power supplies parallel without conflict, achieving high-reliability redundant architecture
Complete protection mechanism: Overvoltage OVP, overcurrent OCP, overpower, overheat OTP, automatic protection for output short circuit
Power enable/disable control port, can be remotely started/stopped; Power normal PG signal output
High efficiency, high power density, forced air cooling (5CFM external air cooling)

Physical Specifications
Size: 162.5mm × 40.6mm × 100mm (6U CPCI single-width slot)
Interface: 47-pin Positronic standard CompactPCI power connector
Heat dissipation method: External forced air cooling
Operating temperature: 0℃～+50℃; Storage temperature: -40℃～+85℃
Humidity: 5%～95% RH without condensation

Safety and Certification
Safety certification: UL60950-1, EN60950-1, CE, CSA
Environmental protection standard: RoHS lead-free compliance
Input/output electrical isolation, strong anti-electromagnetic interference capability

Typical Application Scenarios
CompactPCI industrial control chassis, communication switch, industrial measurement and control equipment power supply
Railway transportation, military, aviation, medical equipment CPCI system
Industrial test instruments, servers, security redundant power supply system
Replacement of old CPCI equipment spare parts, system expansion and upgrade
