Product Description
This item is the standard extension cable of Bently Nevada 3300 XL 8mm eddy current proximity transducer system, with total cable length of 8.5 meters and belongs to 330130 series. It adopts 75Ω coaxial cable with FEP insulation and corrosion-resistant gold-plated ClickLoc self-locking connectors for stable connection without special installation tools. The cable features wide temperature adaptability and strong anti-interference performance. It works together with 3300 XL probe and proximitor to build complete shaft vibration & shaft position monitoring system. Series components are interchangeable and backward compatible with legacy 3300 sensor parts. Every cable passes capacitance and electrical performance test before delivery for rotating machinery protection monitoring.
2. Core Product Parameters
- Model Number: 330130-085-00-05
- Series: 330130 series, for 3300 XL 8mm proximity transducer system
- Cable Length: 8.5 m
- Cable Type: Standard coaxial extension cable
- Insulation Material: FEP
- Impedance: 75 Ω
- Connector: Gold-plated ClickLoc self-locking connector
- Operating Temperature: -51℃ ~ +177℃
- Minimum Bend Radius: 25.4 mm
- Typical Capacitance: 69.9 pF/m
- Certification: CN certification
- Matching Parts: 3300 XL 8mm Probe + 3300 XL Proximitor
- Function: Connect proximity probe and proximitor, transmit eddy current signal
3. Product Application
4. Same Series Models
330130-085-00-00
330130-085-01-05
330130-085-01-00
330130-085-02-05
330130-085-02-00
330130-080-00-05
330130-075-00-05
330130-070-00-05
330130-040-00-05
Front and Rear View of Keyphasor module
1) Buffered Transducer Outputs
2) I/O Module, Isolated Internal Termination
3) I/O Module, Isolated External Termination
4) I/O Module, Non-Isolated Internal Termination
5) I/O Module, Non-Isolated External Termination
6) Barrier I/O Module, Internal Termination
Bently Nevada in Stock
| 125712-01 | 330130-040-01-05 | 125800-01 |
| 140734-02 | 330130-080-00-00 | 133388-01 |
| 125744-02 | 330130-00-07-10-02-00 | 133396-01 |
| 133388-02 | 330130-080-00-05 | 125768-01 |
| 127610-01 | 330130-040-00-00 | 138607-01 |
| 149369-01 | 330130-045-00-05 | 146031-01 |
| 136180-01 | 330130-040-00-000 | 125720-01 |
| 128229-01 | 330130-085-00-05 | 149986-02 |
| 125720-01 | 330103-03-09-10-02-00 | 176449-02 |
| 125760-01 | 330103-00-04-05-02-00 | 128229-01 |
| 133442-01 | 330103-00-07-10-02-00 | 127610-01 |
| 125840-01 | 330703-000-070-10-02-00 | 125840-01 |
| 133396-01 | 330104-00-20-05-02-00 | 133300-01 |
| 125800-01 | 330106-05-30-10-02-00 | 3500/05-01-01-00-00-00 |
| 133323-01 | 330106-05-30-05-02-00 | 330106-05-30-10-02-00 |
| 135137-01 | 330171-00-94-10-02-00 | 330104-00-09-10-02-00 |
| 125768-01 | 330730-040-00-00 | 330104-00-08-10-02-05 |
| 3500 FUTURE EXPANSION | 330854-040-24-05 | 18745-03 |
| 330130-040-00-00 | 330730-080-00-00 | 330180-50-00 |
| 330100-90-01 | 330180-51-00 | 147663-01 |
| 330100-90-00 | 9200-01-05-10-00 | 125840-01 |
| 24583-04 | 991-25-70-01-01 | 3500/50 133388-02 |
| TK3-2E | 125680-01 | 133442-01 |
| 135489-01 | 172103-01 | 3500/33 149986-01 |
| 140471-01 | 136188-02 | 3500/20 125744-02 |
| 3500/15 | 138708-01 | 3500/90 125728-01 |
| 330130-040-01-00 | 149992-01 | 3500/42 125672-02 |
| 330130-045-01-00 | 128240-01 | 3500/42M 140734-02 |
