3500/94M 190214-01 is the VGA display module of the Bently Nevada 3500 series mechanical protection system. The following is a detailed introduction to this product:
I. Product Features
Core Function: As the main module of the 3500/94M VGA display system, it is the core unit for displaying critical mechanical health information in the system rack or control room.
Display Capability: Supports real-time visualization of system event lists, alarm event lists, and data from all modules/channels (such as vibration level, bearing temperature, speed, gap voltage).
Interaction Design: Equipped with a touch screen interface, users can directly operate data on the display; supports up to nine customizable display screens to meet personalized monitoring needs.
Installation Flexibility: Offers VGA touch screen displays in sizes of 10 inches or 15 inches, supporting front installation, rack installation, panel installation, or standalone installation.
Expansion Capability: Through KVM extenders, the display can be installed up to 10 kilometers away, suitable for large facilities or remote monitoring; optional display router boxes can be selected to achieve single-display monitoring of multiple rack data.
Self-Diagnosis Function: Integrates LED status indicators (such as OK LED, TX/RX LED), which display real-time operating status and communication activities, facilitating rapid fault diagnosis.
Environmental Adaptability: Designed specifically for industrial environments, with a working temperature range of -20°C to +65°C, and a sturdy and reliable structure.
Application scenario
Rotating machinery monitoring: Widely applied to real-time monitoring of parameters such as vibration, temperature, and speed of key rotating equipment like steam turbines, compressors, and generators.
Fault early warning system: Through continuous data collection and analysis, it can identify mechanical fault signs in advance, reducing the risk of unplanned downtime.
Remote operation support: Combined with KVM extenders and display routers, it enables centralized monitoring and management of cross-regional equipment clusters.
