Product Description
60R/PPM01‑02‑2 is the Protection Processing Module (PPM) for Bently Nevada (Baker Hughes) Orbit 60 series machinery protection and condition monitoring system. It is the core computing unit of the protection system, slot‑mounted in system chassis. This module processes real‑time sensor signals including vibration, displacement and temperature, performs measurement calculation, alarm and trip logic judgment, and outputs protection interlock signals. It supports state‑based alarming. Multiple PPM modules can be deployed in parallel for capacity expansion, and redundant configuration is recommended for critical machinery with SIL‑2 functional safety compliance. Configuration, system capacity evaluation and fault diagnosis are implemented via Orbit Studio software. On‑board OK and LINK LED indicators facilitate on‑site maintenance. This model is active‑production for new projects and system retrofitsBaker Hugh….
Technical Data
| Item | Specification |
|---|---|
| Model | 60R/PPM01‑02‑2 |
| Type | PPM Protection Processing Module |
| System | Orbit 60 Series Machinery Protection & Condition Monitoring System |
| Safety Level | SIL 2 |
| Certifications | ATEX, IECEx, CSA, CE, UKCA |
| Mounting | Slot‑mount inside Orbit 60 chassis, single‑slot occupancy |
| Power Supply | Backplane 24 VDC chassis power |
| Diagnostics | OK status LED, LINK internal communication LED |
| Configuration Software | Orbit Studio (configuration, diagnosis, system utilization calculator) |
| Expansion | Multi‑PPM parallel expansion; redundancy recommended for protection systems |
| Operating Temperature | ‑20℃～+60℃ |
| Humidity | 5‑95% RH, non‑condensing |
| Dimensions | 132.1 × 20.3 × 245.6 mm |
| Weight | Approx.1.2 kg |
| Lifecycle | Active production, regular delivery |
Applications
Widely used for critical rotating machinery such as steam turbines, gas turbines, compressors, fans and pumps in power, petrochemical, metallurgy and oil‑gas industries. It delivers real‑time calculation, alarm and trip interlock for shaft vibration, shaft displacement, housing vibration, key‑phasor and temperature channels. Suitable for green‑field projects and legacy‑system retrofits, providing early fault warning and minimizing unplanned downtime.
