Bently Nevada 86517-01-01-01-02 Acceleration/Dynamic Pressure Interface Module

The Bently Nevada 86517-01-01-01-02 is a high-precision charge amplifier interface module designed for the Bently Nevada 3500 machinery protection system, serving as a core supporting component for industrial mechanical condition monitoring. It is mainly compatible with piezoelectric accelerometers and dynamic pressure sensors, converting weak sensor charge signals into standard voltage signals to realize accurate acquisition and transmission of rotating machinery vibration, impact and dynamic pressure data, providing reliable data support for unit fault early warning, condition analysis and protection interlock.

Equipped with fixed filter bandwidth and standard bias voltage output, the module features electrical isolation, loop self-inspection and fault diagnosis with excellent industrial adaptability. It is widely used in online monitoring systems for major rotating equipment such as thermal power units, gas turbines, fans and compressors, acting as an essential front-end signal conditioning unit in the Bently Nevada 3500 machinery protection system.

Full Model: 86517-01-01-01-02

86517: Series code, charge amplifier interface module for acceleration and dynamic pressure monitoring
1st 01: Filter configuration, fixed 25Hz high-pass & 350Hz low-pass cutoff frequency
2nd 01: DC bias configuration, standard -10VDC signal bias output
3rd 01: Standard electrical interface version, universal industrial configuration
4th 02: Certification level, CENELEC (SIRA) compliant certified version

As a dedicated front-end signal conditioning device for rotating machinery condition monitoring, this module is mainly used for the acquisition and transmission of vibration, impact and dynamic pressure signals of major industrial dynamic equipment, providing data support for unit protection, fault diagnosis and predictive maintenance. The core application scenarios are as follows:

Power Generation Industry: Online vibration and dynamic pressure monitoring for key auxiliary equipment such as thermal power units, gas turbines, steam turbines, induced draft fans and forced draft fans to ensure safe and stable operation of main equipment.
Petrochemical Industry: Condition monitoring of rotating equipment such as compressors, boosters, pump groups and reactor supporting equipment in refining and chemical plants, adapting to explosive and high-risk plant environments.
Oil & Gas Energy Industry: Precision condition monitoring of large rotating machinery in offshore platforms and oil & gas transmission stations to realize early equipment fault warning and hidden danger investigation.
Heavy Industry Manufacturing: Vibration feature collection, fault analysis and condition evaluation for high-speed operating equipment such as large fans, air compressors and turbine units.
Industrial Technical Renovation & Maintenance: 3500 monitoring system measuring point expansion, old module replacement, signal loop optimization and unit monitoring system upgrading and renovation projects.
