I. Basic Information
Brand Ownership: Bently Nevada (a subsidiary of Baker Hughes, Bently)
Full Model Number: TACH100-01, Original Equipment Manufacturer Part Number 174652-01
Product Positioning: Independent local speed display instrument, not a 3500 rack plug-in module; used for on-site real-time speed display of steam turbines, gas turbines, and compressors, can be connected in parallel with the 3500 TSI system to share the same keyphasor signal, achieving dual-speed monitoring in the control room and at the machine side, meeting the dual-speed safety monitoring requirements of the unit. Baker Hughes… 。
Product Lifecycle: Current general spare parts, not discontinued; available for maintenance and inspection of power plants and refineries’ existing units.
Core Functions
Local high-precision speed display
Receive signals from Bentley phase detector / eddy current preamplifier, and display the shaft speed RPM in real time on the LED digital tube locally; no need to rely on the 3500 rack in the control room; it can complete speed monitoring independently.
Sensor power supply output
The instrument comes with -24V DC power supply, which can directly drive 1 Keyphasor eddy current probe without the need for an additional preamplifier power supply.
Dual systems parallel compatibility
The signal lines can be connected in parallel to the input terminals of the 3500/25 phase detector module, and one probe signal can simultaneously supply the TSI system of the rack and the local speed meter, providing redundant speed monitoring for overspeed protection double verification.
Parameter self-configuration
Panel buttons set the number of pulses per revolution (1~99), signal trigger threshold, and hysteresis voltage, suitable for different tooth count speed measurement gears.
Industrial signal fault tolerance
Automatic signal threshold adjustment, compatible with magnetic resistance MPU and eddy current phase detector input.
Electrical and Measurement Specifications
1. Measurement Performance
Speed range: 0 ~ 100000 RPM
Measurement accuracy: Reading ±0.5%
Display resolution: 0.1 RPM
Input signal: Eddy current probe (-24V preamplifier), passive magnetic resistance speed detector VRS pulse
Hysteresis adjustable range: 0.2V ~ 2.5V DC, modified by the on-site buttons
Pulses per revolution: 1~99 can be set arbitrarily
2. Power Supply Specifications
Standard version TACH100-01 power supply: 110/230V AC 50/60Hz AC power supply, the entire machine comes with isolated power supply, power consumption ≤ 5W, can output -24V/20mA to drive the probe.
3. Environmental Parameters
Standard working temperature: 0℃ ~ +60℃; storage: -40℃ ~ +85℃
Humidity: Maximum 95% RH, no condensation
Protection: Panel IP54, installation in the cabinet of the entire machine IP20
Certification: CE, EMC industrial electromagnetic compatibility certification
4. Mechanical Dimensions
Installation method: Embedded panel with opening for installation
Form size: Width 139.7mm × Height 76.2mm × Depth 149.1mm
Overall machine weight: 1.13kg
Hardware Panel and Wiring
Front panel
6-digit high-brightness digital RPM display; MENU, up/down three configuration keys; operation status indicator light.
Back terminal block
AC power input L/N/ ground
Phase detector signal + common terminal (-24V power output)
Optional 4–20mA analog output (some versions), remote transmission of speed to PLC/DCS
