CBM E8 24DC/0.5-10A NO-R Electronic Circuit Breaker

Product Description

CBM E8 24DC/0.5-10A NO-R (Order No. 2905744) is an 8-channel 24VDC electronic device circuit breaker of Phoenix Contact CBM series, with independently adjustable rated current per channel and active current limiting protection. It adopts tool-free Push-in connection and 35mm DIN rail mounting. It protects 24V DC loads against overload and short circuit. Built-in intelligent current analysis distinguishes normal load, capacitive inrush current, overload and short circuit. Early warning is triggered when channel current exceeds 80% of set value. NO-R normally-open remote signal contact transmits fault status remotely. Electronic lock prevents accidental modification of current settings. Single channel fault will not cause total power dip. Widely used for protection of sensors and actuator / solenoid valve circuits in automation control cabinets.

Specifications

• Part No.: CBM E8 24DC/0.5-10A NO-R, Order Code: 2905744
• Brand: Phoenix Contact
• Series: CBM Electronic Device Circuit Breaker
• Channels: 8 independent output channels
• Rated Voltage: 24VDC; Operating Range:18~30VDC
• Per-channel adjustable current: 0.5A / 1A / 2A / 4A / 6A /10A
• Max total input current: 80A DC (dual feed, 2×6mm² cable)
• Short-circuit breaking capacity: 300A
• Protection: Active current limiting, overload, short circuit, under/overvoltage detection
• Pre-warning: Early alarm when current >80% of setpoint
• Remote feedback: NO-R normally open contact for remote fault signalling
• Connection: Push-in tool-free wiring
• Mounting: 35mm standard DIN rail
• Dimensions: W41mm × H130mm × D121mm
• Weight: approx. 0.306kg
• Certifications: UL, cUL, DNV GL, RoHS; Pollution degree 2, Protection Class III
• Flame rating: UL94 V0

Applications

1. Circuit protection for 24V DC sensors, proximity switches and encoders in industrial automation cabinets
2. Load protection for PLC digital outputs, solenoid valves and small DC actuators
3. Branch 24V DC power distribution protection inside DCS and SIS control panels
4. DC power distribution protection for electrical cabinets on ships and offshore platforms (DNV approved)
5. Multi-channel 24V power distribution and protection for packaging machinery, conveyors and test benches

CBM Series Part Numbers

• CBM E4 24DC/0.5-10A NO-R: 4 channels, 0.5~10A adjustable, NO remote contact
• CBM E8 24DC/1-4A NO-R: 8 channels, low current version 1~4A
• CBM E8 24DC/0.5-10A NC-R: 8 channels,0.5~10A, NC remote contact
• CBM E10 24DC: 10-channel CBM electronic circuit breaker
• CBM S4 24DC: Compact 4-channel economical type
