DEIF OPM-1 Switching Output Module

DEIF OPM-1 Switching Output Module
I. Product Description
DEIF Delomatic-3 modular power station control system, 19-inch card-type relay output module, installed in the DGU2 control cabinet; receives the main control instructions of the system, provides multiple passive relay dry contact outputs, serving as the interface between the controller and the on-site actuating elements, and completing the switch quantity output functions such as unit start-stop, circuit breaker control, fault alarm, and indicator light driving.

Key Technical Parameters
Power Supply: 24 V DC (±10%)
Output Channels: 16-channel relay passive contact outputs
Communication Bus: Delomatic-3 internal CAN system bus
Installation Form: Backplane slot plug-in installation of DGU chassis
Maximum Number of Units Per Chassis: Up to 8 units
Operating Temperature Range: -10 ℃ ~ +60 ℃
Protection Grade: IP20 (used in control cabinet)
EMC Standard: Complies with maritime IEC 61000 electromagnetic compatibility specifications
Status Indicators: Built-in LED indicators for operation, communication, and channel status

Product Performance
16 independent relay contacts, software-free control logic allocation;
Passive dry contact outputs, suitable for various on-site loads of AC and DC;
Support for live module insertion and removal, no need to power off the entire machine for maintenance and replacement;
Real-time reception of master control instructions by the bus, rapid output response;
Channel status diagnosis, abnormal information upload to the system master control;
Maritime reinforced design, resistant to vibration and electromagnetic interference, suitable for harsh working conditions in engine rooms;
Modular expansion, increase output points as needed, suitable for large and small power station schemes.
IV. Application Domains
Power management systems for various merchant ships, offshore platforms, and ship automation power stations
Multi-machine parallel power stations for land-based diesel generators, emergency power control systems
Independent power supply systems for ports, mines, factories, logic control
Start-stop, protection, and alarm control for mobile power stations, offshore platform generators
External execution drive for automatic synchronization, load distribution system of generators

Modules of the Delomatic-3 Series
OPM-1 Switching Output Module
IPM-1 Intelligent Power Management Input Module
IPM-2 Input Acquisition Module
AOM-1 Analog Output Module
SCM-2 Synchronization Control Measurement Module
CM-2 System Master Control Module
PSM-1 System Power Module
COM-1 External Communication Expansion Module
