Product Description
Delta Tau ACC‑70E (Part No.603962‑102) is a MACRO fiber‑optic ring communication expansion board for UMAC / Turbo PMAC motion control system, 3U UBUS rack plug‑in card. It establishes high‑speed real‑time fiber communication between main controller and remote MACRO servo drive nodes for distributed multi‑axis motion control network. Fiber‑optic transmission provides excellent immunity against industrial electromagnetic interference. It supports MACRO ring topology for servo‑axis expansion. Compatible with UMAC and Turbo UMAC rack systems.
Technical Specifications
| Item | Specifications |
|---|---|
| Model | ACC‑70E, PN:603962‑102 |
| Form Factor | 3U UBUS backplane plug‑in card for UMAC rack |
| Protocol | MACRO (Motion And Control Ring Optical) fiber‑optic motion control ring |
| Interfaces | Dual fiber ports for MACRO ring; UBUS backplane interface to CPU |
| Topology | Redundant dual fiber ring, node bypass support |
| Communication Speed | 100 Mbps MACRO real‑time fiber bus |
| Compatibility | Turbo PMAC, UMAC, Power UMAC motion controllers |
| Function | Connect MACRO servo nodes, expand distributed servo axes |
| Operating Temperature | 0℃ ~ +55℃ |
| Storage Temperature | -25℃ ~ +70℃ |
| Humidity | 10‑95%RH non‑condensing |
| Status | OEM discontinued; supplied as used / refurbished spare parts |
Applications
- Distributed servo control for multi‑axis high‑precision automation equipment, MACRO fiber ring network construction
- Motion control for semiconductor machinery, precision processing machines, laser processing and automatic test equipment
- System expansion for UMAC / Turbo‑PMAC, adding remote servo drive nodes
- Legacy‑equipment spare‑part replacement & retrofit for sites with heavy electromagnetic interference
Delta Tau MACRO / Communication Series Boards
- ACC‑71E: MACRO slave interface board for local MACRO axis connection
- ACC‑72EX: Fieldbus expansion board, supports EtherCAT, Profinet, EtherNet/IP and other industrial Ethernet protocolsManualsLib
- ACC‑73E: MACRO fiber repeater board for extended fiber‑ring transmission distance
