EATON XV-102-B5-35TQR-10-PLC Human-machine interface – Controller panel

The Eaton XV-102-B5-35TQR-10-PLC is a 4.4-inch human-machine interface (HMI) device powered by 24V DC electricity, launched by Eaton Company. The following is a detailed introduction to this product:
I. Product Overview
Manufacturer: Eaton, a leading manufacturer in the electrical field.
Product type: Human-machine interface (HMI) controller panel, specially designed for the industrial automation sector.
Power requirements: 24V direct current supply, in line with common power standards for industrial automation equipment.
Main features
Display: 4.4-inch TFT color touch screen, providing clear and intuitive visual experience, facilitating operators’ monitoring and operation of the equipment.
Touch technology: Supports multi-touch (specific touch technologies may vary by model, but Eaton HMI products typically adopt advanced touch technologies), making operation more flexible and convenient.

Rich interfaces:

Equipped with various communication interfaces, such as Ethernet (Ethernet), RS-232, RS-485, CAN, etc., enabling seamless connection with PLCs, sensors, drivers, etc., for real-time data transmission and sharing. Some models also support the SmartWire-DT communication system, further simplifying wiring and reducing engineering costs.
Storage expansion: Supports SD card or USB expansion to meet data storage needs, facilitating data backup and program upgrades by users.
Operating system and programming: Compatible with various operating systems and programming software platforms, such as Windows CE, Linux, Windows Embedded, and Eaton’s own platform, supporting Galileo, CoDeSys, Vijeo Designer, etc., providing an intuitive graphical programming interface, reducing programming difficulty.
Protection level: The panel typically reaches IP65 protection level (front side), suitable for harsh industrial environments, such as dust-proof and water-proof, ensuring the stable operation of the equipment.

Operating temperature range:

Supports a wide operating temperature range (specific range may vary by model, but usually meets the requirements of industrial environments), ensuring stable operation in extreme environments.

Application scenarios
Production line monitoring: Graphically presents production processes and process data, real-time monitors equipment status, improving production efficiency.
Automation equipment control: Displays equipment operating parameters, supports start-stop operations and parameter settings, achieving automated control of equipment.
Energy and building management: Monitors energy consumption, equipment operation status, and triggers alarm prompts, helping users achieve effective energy management and intelligent control of buildings.
Industrial control cabinet: As a control and visualization platform for PLCs or remote I/O, simplifying the design and operation of the control system.
Special industries: Such as packaging, food, textiles, mechanical processing, etc., supporting local control and remote monitoring, meeting the needs of different industries.
