EBMPAPST A2E200-AF02-01 AC Axial Flow Fan

EBMPAPST A2E200-AF02-01 AC Axial Flow Fan
I. Basic Information
Brand: EBMPAPST (Germany, Ibeianpat)
Complete Model: A2E200-AF02-01
Original Factory Order Number: 166149
Fan Type: Single-phase AC Axial Flow Fan, with Circular Air Deflector
Matching Motor: M2E068-CA Capacitor-Driven Motor

Core Electrical Parameters (50Hz/230VAC)
Power Supply: 230VAC 50Hz, single phase
Standard Starting Capacitor: 1.5μF / 400VDB
Rated Operating Conditions (50Hz)
Speed: 2740 r/min
Power: 50W
Current: 0.24A
Peak Operating Conditions (No Back Pressure)
Speed: 3120 r/min
Power: 61W
Current: 0.28A
Maximum Airflow: 740~830 m³/h
Maximum Static Pressure: 200 Pa
Starting Current: 0.53A

Mechanical and Environmental Specifications
Size: Outer Diameter of the Impeller 200mm, Overall Thickness of the Machine 68mm
Blades: 5 Plastic Air Blades
Bearings: Ball Bearings, Long-life Design
Protection Grade: IP44
Insulation Grade: B Class
Operating Temperature: -25℃ ~ +75℃
Storage Temperature: -40℃ ~ +85℃
Rotation Direction: Looking at the impeller from the front, rotate counterclockwise
Airflow Direction: V-shaped (Air enters from the side of the motor, and exits from the side of the air ring)
Certifications: CE, VDE

Air volume and air pressure performance curve

 Model Segmentation Explanation
A2: AC axial flow fan series
200: Impeller diameter 200mm
A: Motor structure; F: Circular air ring structure
02-01: Motor, installation, wiring version code

Typical Application Scenarios
Wind power pitch control cabinet cooling (standard configuration in the wind power industry)
High-power frequency converter, inverter cabinet cooling
Industrial control cabinet, UPS, SVG cooling
Laser equipment, welding equipment, power module ventilation
Small air conditioner, purification equipment
