ELAU MC-4/11/03/400 Detailed Description
Product Overview
The ELAU MC-4/11/03/400 is a high-performance motion controller belonging to the ELAU MC series, specifically designed for multi-axis coordination in small- to medium-scale industrial automation production lines. With powerful computational capabilities and flexible control logic, it precisely coordinates the motion trajectories of up to three axes, playing a critical role in applications requiring high-precision synchronized operation.
This motion controller is widely used in electronic component insertion machines, multi-axis drive systems of small printing presses, and precision assembly lines. In electronic component insertion machines, it accurately controls the movement of insertion heads and PCB boards, enabling fast and precise component placement. In small printing presses, it synchronizes the actions of paper feeding, printing rollers, and paper collection mechanisms to ensure accurate registration of printed patterns. On precision assembly lines, it enables synchronized control of multiple robotic arms across various workstations, improving both assembly efficiency and consistency. Whether handling simple point-to-point positioning or complex trajectory interpolation, the ELAU MC-4/11/03/400 delivers stable and reliable performance, providing strong support for efficient and precise industrial manufacturing.
Product Technical Specifications
Number of Control Axes: Supports 3-axis collaborative control, enabling various control modes such as multi-axis synchronization, linear interpolation, and circular interpolation, meeting the multi-axis linkage requirements of medium and small-scale production lines.
Computational Performance: Equipped with a high-performance processor, with a computing frequency of 1GHz, capable of quickly processing complex motion control algorithms and logical instructions, ensuring the real-time and accuracy of control instructions.
Power Supply Voltage: Input power supply is AC 400V ± 10%, frequency 50/60Hz, compatible with industrial high-voltage power supply environments, ensuring the equipment operates under stable power supply.
Output Power: The maximum output power of a single axis supports 2.0kW, and the total power can be adapted to 3-axis balanced load, capable of driving medium and large-power servo motors, meeting the power requirements of various equipment.
Communication Interfaces: Equipped with multiple communication interfaces such as EtherCAT, PROFINET, and RS485, among which the EtherCAT communication rate is up to 100Mbps, supporting real-time data transmission, facilitating the establishment of an efficient control system network with servo drives, sensors, and upper computers, etc.
Programming Environment: Supports IEC 61131-3 standard programming languages (such as ladder diagrams, structured text, function block diagrams, etc.), and provides a rich motion control function library, simplifying the programming implementation of complex motion trajectories and reducing development difficulty.
Position Control Accuracy: Pulse output accuracy reaches 0.1 pulse, combined with high-precision encoder feedback, can achieve ±0.005mm positioning accuracy, meeting the strict requirements of precision processing and assembly.
Operating Environment: Working temperature range is 0~50°C, relative humidity ≤ 90% (no condensation), capable of operating stably in the regular environment of industrial workshops, adaptable to different production conditions.
Protection Grade: Protection grade is IP20, capable of preventing large solid foreign objects from invading, suitable for installation in control cabinets, avoiding direct exposure to dust or humid environments, ensuring the long-term stable operation of the equipment.
Dimensions: Length × Width × Height approximately 290mm × 190mm × 145mm, compact structure, occupying little space, facilitating integration into various control cabinets, saving installation space.
Application Industries
ELAU specializes in high-end packaging automation. This model is widely used in:
Vertical/Horizontal high-speed packaging machines, bag-making machines, filling machines
Food, pharmaceutical aseptic production lines, labeling, cutting equipment
Multi-axis synchronous conveying, precision assembly manipulators, printing tension control systems
There are no reviews yet.
