GE 1SVR040000R1700 Universal Signal Converter

Product Description

1SVR040000R1700 (also named CC-U/STD) is ABB universal signal converter, not GE product. It is a DIN-rail mounted analogue signal conditioning module. It supports more than 120 configurable signal modes and provides 3-way galvanic isolation among input, output and power supply. It isolates, converts and amplifies voltage and current analogue signals. It allows configurable high/low fail-safe output when input signal loss occurs. The signal output is short-circuit protected. Plug-in terminals simplify field wiring and maintenance. It eliminates ground loop interference on site and ensures stable signal acquisition for PLC and DCS systems.

Specifications

• Model: 1SVR040000R1700 (CC-U/STD)
• Brand: ABB
• Product Type: Universal analogue signal converter / signal isolator
• Power Supply: 24V AC / 24~48V DC
• Input Signals: 0~10V, 0~20mA standard analogue signals
• Output Signals: 0~11V, 0~55mA
• Isolation: 3-way galvanic isolation (Input, Output, Power)
• Accuracy: 0.1% of full scale
• Mounting: DIN rail mounting
• Dimension: 75 × 22.5 × 107 mm
• Operating Ambient Temperature: -20℃ ~ +60℃
• Storage Temperature: -40℃ ~ +80℃
• Features: Configurable fail-safe output on signal loss, short-circuit proof output, front rotary configuration, pluggable terminals
• Certifications: CE, RoHS
• Status: Obsolete by manufacturer, available as industrial spare part

Applications

1. Process Industry: DCS systems for chemical & petrochemical plants, isolate 4-20mA transmitter signals to eliminate ground potential interference
2. Water Treatment: Analogue signal acquisition from field instruments, protect PLC AI modules from surge damage
3. Power & Energy: Isolation and conversion of temperature & pressure sensor signals for SCADA data collection
4. Factory Automation: Isolation of analogue signals from drives and sensors, signal matching between different control systems
5. Building & HVAC: Signal conditioning for smart instruments, stabilize long-distance analogue signal transmission

Related Series Models

• 1SVR040001R0400: CC-U/STD, wide power supply version (110-240VAC)
• 1SVR040004R0700: Thermocouple dedicated signal converter
• 1SVR040006R0100: CC-I/STD, current input signal isolation module
• 1SVR040002R0000: CC-V/STD, voltage dedicated signal converter
• 1SVR040003R0000: CC-R/STD, resistance / PT100 RTD signal converter
