GE C60-U01-HCH-F8F-H6P-M8F-P6P-U6P-WXX Management and Protection Relay

Product Description

Model: GE C60-U01-HCH-F8F-H6P-M8F-P6P-U6P-WXX, GE Multilin UR Universal Relay series, Breaker Management Relay. It is a microprocessor-based integrated device integrating circuit breaker protection, control, monitoring, oscillography and event recording. It supports FlexLogic programmable logic, built-in power metering, abundant I/O expansion and multiple communication interfaces. It is suitable for dual-breaker configurations such as breaker-and-half and ring bus schemes. Equipped with powerful fault diagnosis and waveform recording functions, widely applied in high-voltage circuit breaker protection package, substation retrofitting and OEM spare parts replacement.

Specifications

• Model: C60-U01-HCH-F8F-H6P-M8F-P6P-U6P-WXX
• Brand: GE (GE Vernova / Multilin)
• Series: UR Universal Relay
• Product Type: Breaker Management Relay
• CPU: U01 (RS485 + Dual 100BaseFX Multimode Fiber SFP + 100BaseT Ethernet)
• Mounting: H, Horizontal 19” rack mount
• HMI: C, Standard front panel
• Power Supply: H, 125/250V AC/DC universal supply
• CT/VT DSP: F8F, 4CT/4VT with enhanced diagnostics
• Digital Output: H6P; Digital Input: M8F; Communication Expansion: P6P, U6P; WXX: No extra software option
• Event Recorder: Up to 1024 time-tagged events
• Oscillography: Up to 64 records, programmable sampling rate
• Time Synchronization: IRIG-B, SNTP, PTP
• Operating Temperature: -40℃ ~ +85℃
• Communication Protocols: IEC 61850, Modbus TCP, DNP3, IEC 60870-5-103
• Logic Engine: FlexLogic™ user programmable logic

Application

1. Protection, control and condition monitoring of high-voltage circuit breakers in substations;
2. Protection & measurement for breaker-and-half and ring bus dual-breaker schemes;
3. Switchgear integrated protection for power plants and industrial captive power stations;
4. Power system fault waveform recording, sequence of events logging and electrical metering;
5. Retrofit of legacy substation protection systems and replacement of original UR series spare parts.

Related Series Models

C30, C95, D60, F60, B30, G60, L90, M60, T60
