GE ES0601 / 1C754VSL06MTD-KH Module
Brand: GE General Electric
Series: GE Fanuc / Mark VIe Turbine Control System
Model: Main model ES0601, Part Number 1C754VSL06MTD-KH
Category: Steam Turbine / Gas Turbine Special Speed Detection Module / Rotational Speed Monitoring Card Product Overview
This module is a dedicated speed acquisition and control module for GE energy systems. It is mainly used in gas turbine and steam turbine power generation unit control systems. It accurately collects the pulse signals of the unit’s speed, completes speed calculation, overspeed protection, and speed regulation logic operations. It has strong stability and high anti-interference ability. It is a core spare part for power station DCS and turbine protection systems. It is fully compatible with the original equipment and can be replaced with general products.
Key parameters
Input signal: Pulse signal from magnetic resistance speed sensor
Operating voltage: 24VDC system power supply
Measurement range: Full coverage from low speed of the unit to rated full speed
Communication protocol: Compatible with Mark VIe system internal bus communication
Operating temperature: -10℃ ~ +65℃
Installation form: Rack-mounted slot installation
Function modes: Speed monitoring, overspeed trip, speed closed-loop control
Protection level: Industrial cabinet standard IP20
Compatible systems: GE Mark VI, Mark VIe gas turbine and turbine control systems
Main features
High-precision speed sampling, fast response
Built-in signal filtering, suitable for industrial strong electromagnetic environments
Supports synchronous collection and comparison of multiple speed signals
Equipped with fault self-check and status alarm output
Original program固化， plug-and-play， no need for debugging
Special for power generation units， stable and durable in long-term operation
Application fields
Steam turbine control system of thermal power plants
Gas turbine power generation control system
Main control system of combined cycle power plants
Unit protection of large industrial self-owned power plants
GE complete set control system spare parts replacement in the energy and power industry
