GE GUVT240 Unit Voltage Acquisition Monitoring Module Detailed Explanation
1. Model Classification and Positioning
`GUVT240` belongs to the **GE (now Vernova) Mark VI/Mark VIe Turbine and Generator Control System Special Voltage Conditioning Acquisition Card**. GUVT is the exclusive voltage monitoring series name of GE. The 240 represents the ability to adapt to rated 240V AC voltage measurement points for acquisition, and it is the same as the wind power main control board `IS215WECAH1A` you previously queried. They both belong to the unit control hardware product line, mainly undertaking the tasks of generator terminal PT transformer voltage sampling and excitation circuit voltage feedback acquisition, and are compatible with thermal power / hydropower / gas turbine control cabinets.
Core Hardware Specifications Table
Parameter Item | Specification Details
Input Compatibility | Three-phase PT secondary AC voltage, rated input up to 240VAC, compatible with 50/60Hz power frequency
Circuit Characteristics | Independent channels with electrical isolation, built-in filtering and surge suppression, resistant to electromagnetic interference from high-power components in the excitation cabinet
Power Supply Method | Mark series chassis backplane uniformly draws DC24V power Installation Form | Standard 6U slot embedded installation, cabinet IP20 indoor protection
Operating Temperature Range | -30℃~+65℃, suitable for high and low temperature fluctuation conditions in power station machine rooms
Output Link | Pre-processes signals and transmits them to the main control computing unit, supports over-limit alarm and interlock trip signal linkage Self-Diagnosis Capability | Equipped with real-time diagnosis for open circuit, over-range, and channel faults, and actively reports abnormalities to the system
Typical Application Scenarios
Power generation / hydroelectric turbine units, gas turbine control cabinets, participate in the determination of grid connection synchronization, excitation closed-loop voltage regulation, and voltage fault protection; it can be combined with GE IS215WECAH1A wind power main control board and ABB UV5627B-E vibration monitoring card, covering dual operation and maintenance monitoring of voltage regulation and mechanical vibration for the units.
