GE H201Ci-1 (HYDRAN®201i) Single Channel Dissolved Gas Monitoring Controller
Product Description
H201Ci-1 belongs to GE Vernova HYDRAN 201i family, a single-channel controller designed to work with H201Ti intelligent transmitter to form an on-line dissolved gas monitoring system for oil-filled power equipment. It receives gas data from H201Ti, performs data processing, local LED concentration readout, multi-level alarm, analog output and network communication. Housed in NEMA 4X (IP66) weatherproof enclosure for outdoor installation, equipped with built-in self-diagnostics to detect incipient transformer faults such as partial discharge, overheating and arcing. It supports network architecture, up to 128 H201Ti transmitters can be connected to one controller network. The full set H201Ci-1 + H201Ti is named HYDRAN 201R Model i, widely used for transformer condition assessment and predictive maintenance.
Technical Specifications
- Channel Configuration: Single channel controller for one H201Ti intelligent transmitter; network expansion up to 128 H201Ti units
- Display: Digital LED display, measuring range 0–1999 ppm; local visualization of gas concentration and alarm status
- Analog Output: Standard non-isolated analog output, jumper configurable: 0–1mA / 4–20mA / 0–1V / 0–10V (0–2000 ppm scale); optional 2nd isolated analog output with 1500V RMS isolation
- Alarm Relays: Gas High, Gas High-High and system fault alarms, form C contacts; contact rating:125VA/250VAC,60W/220VDC
- Communication: RS485 (Modbus RTU), RS232; optional external modem for remote access; optional Ethernet expansion module
- Power Supply: 85–264VAC,47–63Hz; optional 24VDC; power consumption＜15W
- Environment: Operating temperature -20℃ ~ +70℃; humidity 5~95%RH non-condensing
- Enclosure Rating: NEMA 4X (IP66), weatherproof outdoor cabinet with vibration isolation mounting pads
- Diagnostics: Built-in self-diagnosis for sensor failure, communication loss and power failure
- Monitored Gases (by H201Ti): Hydrogen H₂, Carbon Monoxide CO, Ethylene C₂H₄, Acetylene C₂H₂
Applications
- On-line dissolved gas monitoring for oil-filled power transformers, auxiliary transformers and reactors to identify incipient faults (overheating, partial discharge, arcing)
- Transformer condition monitoring in power plants and substations; trend logging and early warning for condition-based maintenance
- Integration with SCADA / DCS systems for remote reading of gas concentration and alarm signals
- On-line monitoring of large oil-filled power assets in petrochemical and metallurgical industries
- Smart grid asset health management to reduce unplanned transformer outages
HYDRAN 201i Family Models
- H201Ci-1: Single Channel Controller (this model)
- H201Ci-C: Communication Controller (no local display, network gateway only)
- H201Ti: HYDRAN 201i Intelligent Dissolved Gas Transmitter (sensor probe unit)
- HYDRAN 201R Model i: Complete system (H201Ci-1 + H201Ti)
- HYDRAN 201i: General designation for the full dissolved gas monitoring system
