GE IC695CPK330 (PACSystems RX3i High Performance CPU Processor Module)

GE IC695CPK330 (PACSystems RX3i High-Performance CPU Processor Module)
This model belongs to the RX3i PAC control system flagship CPU of GE Fanuc (now Emerson Automation), featuring high-speed computing, multi-network interface redundancy, large-capacity storage, suitable for large and medium-sized industrial production lines, power plant DCS, and complex automation projects, occupying 2 slot positions on the rack.
I. Core Hardware Parameters
Table
Item Details
Processor Frequency 1GHz
Memory Configuration 64MB RAM for operation + 64MB non-volatile storage, equipped with an on-board power storage pack (energy group), automatically saves programs/data upon power loss
Expansion Storage Supports CFast high-speed storage cards
Network Interface Configuration 3 10/100/1000Mbps adaptive gigabit network interfaces; 2nd and 3rd interfaces have built-in embedded switches, supporting MRP ring network redundancy, PROFINET system redundancy
Other Interfaces 1 USB2.0 (for debugging / copying programs), 2 RS232/485 serial ports
Backplane Compatibility Dual-bus design, compatible with RX3i PCI bus, old 90-30 serial bus, mixed installation of old and new modules
Expansion Limit Up to 32 I/O modules locally; 20 redundant remote stations, up to 255 remote stations for PROFINET expansion
Operating Environment Operating temperature 0~60℃, industrial anti-interference design

Communication and Protocol Capabilities
Mainstream Ethernet Protocols: SRTP, Modbus TCP, EGD, OPC UA server, PROFINET controller (supports CPU hot backup redundancy), DNP3, can be connected to upper computers, SCADA, servo, instrument equipment;
Serial Port Protocols: Modbus RTU, SNP, ASCII, directly connect to old serial sensors, frequency converters;
Topology flexibly supports star, linear, and ring networking, suitable for long-distance factory distributed control.

Key Functional Highlights
Power-off Protection Energy Storage Unit: In case of sudden power loss, relying on the built-in energy storage unit, the engineering parameters are completely written to the non-volatile flash memory to avoid program loss, no need for additional spare battery maintenance;
Hardware and software redundancy supports dual CPU hot backup architecture, network interfaces can form ring network link redundancy, significantly reducing downtime risks;
Downward compatibility with old equipment allows for mixed mounting of RX3i and Series90-30 modules, upgrading old production lines does not require overall replacement of the rack;
High-speed computing performance is more than 2 times higher than the IC695CPK320 series, suitable for complex logic, batch data collection, and simple motion linkage scenarios;
Programming is compatible with the Unity Pro platform for development, programs can be cross-transplanted across GE’s multiple hardware, low modification cost.

Typical Application Scenarios
Energy and Power: Power plant auxiliary equipment DCS monitoring, wind turbine pitch control, pump station cluster scheduling;
Manufacturing Automation: Large packaging production lines, logistics sorting lines, glass tempering furnace entire line control;
Process Industry: Chemical workshop interlocks, water treatment multi-site distributed control;
Old production line upgrade: Expanding and upgrading the 90-30 system, reusing existing I/O modules to reduce costs.
