Model: IC697CMM742 (Type 2 Second Generation Ethernet Interface Module)
system： GE Fanuc Series 90-70 Large PLC Rack System
Product type： PLC Ethernet communication processor module， used for 90-70 PLC to connect to local area network， upper-level SCADA， data exchange between multiple PLCs， and remote program download and debugging
Installation： Single slot installation in the rack， up to 4 of this module can be inserted in one rack to expand multiple Ethernet communications
Hardware Interfaces (3 Ethernet ports， only one can be used at a time)
RJ45 10BaseT： Twisted-pair Ethernet (most commonly used， connects to switches， HMI， upper-level computer)
BNC 10Base2： Thin coaxial cable interface， used for old industrial bus networking
15-pin AUI interface： Can be externally connected with transceivers to expand various Ethernet media such as fiber optics and thick cables
Included RS485 debugging serial port： Used for local firmware upgrade and module initialization configuration
Built-in replaceable 12VDC fuse， with hardware short-circuit protection
Panel 4 status indicator lights
MODULE OK： Module self-check is normal， constantly on， off indicates hardware failure
LAN ONLINE： Ethernet link has been established
SERIAL ACTIVE： RS485 serial port communication data flashing
STATUS OK： Network protocol is running normally
Core Communication Functions
EGD Ethernet Global Data： High-speed periodic sharing of register data between multiple 90-70 PLCs， achieving interlock and data exchange between PLCs
SRTP/TCP/IP Protocol： Supports remote upload and download of programs by upper-level computer Proficy and IC641 programming software， online monitoring
Connect to SCADA， DCS， touch screens to achieve remote data collection and parameter distribution of PLCs
Support firmware online upgrade， through RS485 port， module firmware can be updated compatible with high-version CPU
Key Electrical Parameters
Power supply： Backplane + 5VDC， maximum working current 800mA
Transmission rate： 10Mbps (10Mbps not supported， only 10M Ethernet)
Operating temperature： 0℃ ~ +60℃， no condensation
Protection level： IP20 (installed only in the cabinet)
Configuration software： Proficy Machine Edition， IC641
Typical Application Scenarios
Power plant， hydropower plant turbine / boiler auxiliary equipment 90-70 PLC control system
Metallurgy， petrochemical large-scale equipment DCS bottom-level PLC communication
Water plant， rail transit， large pump station centralized monitoring system
Renovation of old GE 90-70 equipment， spare parts replacement
