I. Full Interpretation of Model: IC755SUE10CTD-AA
IC755: GE QuickPanel + New Generation Industrial Human-Machine Interface Series (formerly GE Fanuc, now belonging to Emerson Emerson)
SUE: Standard Economy Basic HMI (without built-in PLC control, only monitoring operation)
10: 10.4-inch TFT LCD display
CTD: Color TFT screen, 24VDC power supply, resistive touch (no physical buttons)
-AA: Hardware version / batch suffix for factory production, original factory complete material number, for purchase, spare parts maintenance must include the suffix
Core Hardware Specifications
1. Display and Touch
Screen: 10.4″ Industrial TFT Color LCD
Resolution: 1024×768
Touch: 4-wire resistive touch screen, resistant to oil stains, suitable for rough operations in the workshop
Backlight: LED long-lasting backlight, industrial wide temperature compatibility
Front panel protection: IP65 (embedded installation after)
2. Processor and Storage
CPU: Freescale i.MX535 1GHz ARM Cortex-A8
RAM: 512MB DDR3
Program Flash: 256MB NAND Flash
Backup SRAM: 512KB (battery backup, saves formulas, alarm records)
System: Windows Embedded Compact 7
3. Communication Interfaces (Standard on the Body)
2×RJ45 100Mbps Ethernet (Modbus TCP, GE SRTP, EtherNet/IP)
RS232 / RS485 Serial Ports (Modbus RTU, GE SNP)
USB Host×2 (USB drive program download, mouse, peripherals)
USB Device (connects to computer for configuration download screen)
4. Electrical and Environmental
Power Supply: DC 24V (18–30VDC wide voltage)
Operating Temperature: 0℃ ~ +50℃
Storage Temperature: -20℃ ~ +70℃
Certification: CE, UL, RoHS
Installation: Standard cabinet embedded hole installation
Software and Communication Capabilities
Configuration Software: Proficy Machine Edition (ME), universal programming software for GE’s entire PLC series
Supported Protocols:
GE’s own: SRTP, SNP, VersaMax communication
General Industry: Modbus RTU/TCP, OPC UA, EtherNet/IP
Functions: Screen monitoring, alarm log, process formula storage, data recording, remote web access, email alarm, script logic
Series Comparison (Selection Comparison) Table
Model Positioning Touch Type Internal PLC
IC755SUE10CTD-AA Entry-level monitoring screen Resistive screen No
IC755CKS10CD High-end model Capacitive multi-touch Selectable RSTi-EP IO control
IC755SUE07CTD 7-inch same architecture small screen Resistive screen No
