I. Product Description
Brand: GE Fanuc
Series: VersaMotion S2K Servo Motion Control Series
Base Model: IC8008SI228
IC8008: Integrated Motion Control Unit of S2K Series
SI: Digital Switching I/O Sub-Board
228: 28-channel DI Channel Configuration
Suffix RD2: Hardware Version 2nd Generation, Redundant Power Supply Support
Suffix EE: Industrial Wide-Temperature Enhanced Version, CE/UL Certified Complete Machine
Product Positioning
The S2K servo driver is integrated with a 28-channel 24VDC digital input acquisition unit. It has built-in photoelectric isolation signal conditioning and is integrated in the servo controller body. It is used for machine limit, origin, equipment status, fault alarm signal acquisition, and collaborative logic operation with servo axis control.
Core Hardware Functions
28 DC24V Digital Input Acquisition
The channels are divided into 4 groups (7 points × 4 groups), source type / drain type universal, compatible with proximity switches, travel limiters, dry contact feedback, equipment fault contacts.
Photoelectric Isolation + Hardware Filtering
Single-channel independent optocoupler isolation, built-in RC anti-jitter filtering, suppressing on-site frequency converter, servo strong electromagnetic interference, preventing signal mis-switching.
Board-level Channel Fault Diagnosis
Each channel has an LED status indicator light. Open circuit, short circuit, power supply abnormality are reported to PLC / servo controller in real time, and software pop-up alarm.
Motion Logic Linkage
The collected signals directly participate in servo origin return, hard limit emergency stop, axis enable interlock, response time < 1ms.
Dual Interface Communication
Panel DB9 serial port + terminal bus, supporting Modbus, device network, and data interaction with GE RX3i/RX7i, S2K servo master control.
IV. Key Electrical Parameters
Power Supply: 24VDC ±10%, Total Machine Power Consumption ≤ 2W
Input Level: High level ≥ 11V DC (Effective); Low level ≤ 5V DC
Input Current: Typical single channel 4mA
Isolation Voltage: Channel to Ground 500V AC
Operating Temperature: 0℃ ~ +60℃ (EE Wide-Temperature Version can be -20℃ ~ +70℃)
Protection Grade: IP20 (Cabinet Installation)
Installation: Integrated Rail-mounted Servo Box Integration
Weight: Approximately 1.2kg
Certification: UL, CE, RoHS Industrial Standards
Typical Application Scenarios
Numerical Control Machining Machines, Automation Cutting Equipment Servo Limitation Acquisition
Wind Turbine Pitch Servo Control System Status Signal Acquisition
Packaging, Logistics Sorting Production Line Multi-axis Motion Interlock Control
Old GE S2K Servo Renovation, Spare Parts Replacement Scenarios
Lifecycle and Spare Parts Information
Original Factory Status: GE Fanuc S2K Series全线停产， original factory no longer produces brand new original equipment
Supply Source： Market circulation dismantled original equipment， refurbished and inspected spare parts
Compatible Replacement： Only IC8008SI228RD2-EE of the same model can be directly interchanged； RD1 version cannot be directly substituted
Warranty： Industrial spare parts regular 12-month warranty
