GE IS210BAPAH1A Mark VIe Gas/Turbine Control System

Product Description

Model: IS210BAPAH1A (short name BAPA) Manufacturer: GE Vernova (Former GE Fanuc) System Platform: Speedtronic Mark VI / Mark VIe Gas & Steam Turbine Control System

IS210BAPAH1A is an Analog Processor Module (Acoustic Monitoring Card) for Mark VIe turbine control platform. It is the core board of turbine acoustic monitoring package and must work with SAMB terminal board as a complete acoustic monitoring input pack. It is a narrow VME form factor PCB with conformal coating and front panel LED status indicators. The module collects dynamic vibration and acoustic signals from turbine sensors, performs signal conditioning, DC bias removal and AC amplification, calculates broadband RMS energy within 0~5000Hz. Configuration and diagnostic are realized via ToolboxST software for Frame 6/7/9 heavy-duty gas turbine dynamic monitoring and protection. This OEM part is obsolete. Available stock includes new surplus, used and refurbished tested units.

Technical Specifications

• Part No: IS210BAPAH1A (BAPA)
• Bus: VME bus
• Channels: 18 analog conditioning channels, 24 A/D inputs
• Communication: Dual Ethernet PHY
• Power Supply: 24VDC, powered by rack backplane
• Operating Temperature: -40℃ ~ +70℃
• Humidity: Up to 95% non-condensing
• PCB Protection: Conformal Coating
• Matching Terminal Board: SAMB
• Configuration Software: ToolboxST
• Mounting: Single-slot narrow VME rack module
• Function: Dynamic acoustic & vibration signal acquisition and calculation for turbine

Application

1. For GE Speedtronic Mark VI / Mark VIe control system, applied on gas turbine and steam turbine power generation units.
2. Dynamic acoustic and vibration monitoring for Frame 6/7/9 heavy-duty gas turbines.
3. Thermal power, combined cycle power plant, oil & gas turbine generator set protection and condition monitoring.
4. Spare parts replacement and system retrofit for legacy turbine control systems.
5. Real-time acquisition of dynamic sensor signals, compute vibration/acoustic RMS energy for unit fault early warning and protection interlock.

Related Mark VIe IS210 Series Models

• IS210BAPAH1A: BAPA Analog Processor for acoustic monitoring
• IS210AEBIH1BAB: EBIH Ethernet Interface Board
• IS210AEDBH4AGD: AEDB Digital I/O Module
• IS210AEPSG1AFC: AEPS Power Interface Module
• IS210BPPBH2BAA: BPPB Processor Board
• IS210MAVIH1A: MAVI Analog Input Module
