GE IS215WEPAH1B Mark VIe Wind Turbine Control System

Product Description

GE IS215WEPAH1B (WEPA) is a 30Nm CANBus wind turbine pitch axis control board for GE Vernova Mark VIe wind power control system. It serves as the core control unit of the pitch axis for wind turbines. It controls pitch actuators in real time via CAN bus, executes pitch angle regulation logic, collects feedback signals such as pitch motor position, temperature and current. It is equipped with overvoltage, overcurrent and overheat protection, onboard hardware self-diagnosis and status LED indicators. It cooperates with Mark VIe wind main control system to realize precise blade positioning and safe feathering shutdown. It is obsolete and supplied as spare parts for existing wind farms.

Product Parameters

• Model: IS215WEPAH1B, WEPA 30Nm CANBus Wind Pitch Axis Control Board
• System: GE Mark VIe Wind Turbine Control System
• Function: Wind turbine pitch axis control, CANBus version for 30Nm pitch actuator
• Communication: CAN bus, internal backplane I/O interface
• Protection: Overvoltage, overcurrent, overheat and limit protection
• Diagnostics: Onboard LED status indicators, built-in fault self-diagnosis
• Power Supply: DC24V
• Operating Temperature: -30℃ ~ +65℃
• Humidity: 5%～95% non-condensing
• Mounting: Rack slot mounting for Mark VIe wind control cabinet
• Protection Class: PCB IP20, installed inside control cabinet
• Lifecycle: Obsolete spare part for pitch system maintenance of legacy wind farms

Application

Applied to pitch control system of onshore wind turbines based on GE Mark VIe platform. As axis controller for each blade, it receives angle commands from nacelle main controller, drives pitch motor to adjust blade angle for maximum power tracking, normal shutdown and emergency feathering protection. Widely used in legacy GE wind turbine projects for faulty board replacement in pitch cabinet to ensure safe and stable turbine operation.

Same Series Models

IS215WEPAH1A, IS215WEPAH1B, IS215WEPAH2A, IS215WEPAH2B
