Product Description
GE IS400TCASH1AGD (IS400TCASHIAGD is transcription error) is the TCAS Core Analog Terminal Board for Speedtronic Mark VIe control system, matched with IS230PCAAH1B PCAA analog I/O pack. It acts as the signal interface between field sensors, actuators and PCAA main module, performing multi-channel signal routing, conditioning and isolation protection. It accepts thermocouple, 4-20mA, 0-10V, LVDT, vibration, pulse frequency and servo coil signals. It supports simplex, dual and TMR triple modular redundancy. It provides ≥1500VAC isolation from field side to system side and ≥500VAC between channels, designed for harsh power plant environments with high temperature and strong electromagnetic interference. It is mounted inside Mark VIe rack, connected to PCAA pack via ribbon cable and powered by 28VDC backplane.
Parameters
- Order No.: IS400TCASH1AGD
- Brand: GE General Electric
- System: Speedtronic Mark VIe Turbine Control System
- Type: TCAS Core Analog Terminal Board, companion terminal board for PCAA
- Supported Field Signals: Thermocouple, 4~20mA, 0~10VDC, LVDT excitation & feedback, vibration, pulse frequency, servo coil output
- Redundancy: Simplex / Dual / TMR triple modular redundancy
- Isolation: Field-to-system ≥1500VAC; Channel-to-channel ≥500VAC
- Power Supply: Rack backplane 28VDC
- Interfaces: High-density ribbon cable for PCAA module; P4 shield board connector, P5 backplane power connector
- Mounting: Installed inside Mark VIe I/O rack chassis
- Operating Temperature: 0℃ ~ +70℃ (cabinet ambient)
- Storage Temperature: -40℃ ~ +85℃
- Relative Humidity: 5~95%RH, non-condensing
- Weight: Approx.1.9kg
Product Application
It works with Mark VIe PCAA analog I/O pack for gas turbine, steam turbine and combined-cycle power plant control systems. As field terminal interface, it receives temperature, pressure, vibration and displacement sensor signals, and outputs servo control signals to field actuators for turbine signal acquisition and servo control. Widely deployed in thermal power plants and combined-cycle gas power stations for turbine protection, condition monitoring and turbine unit automation retrofit. It is an essential spare part for GE Mark VIe turbine control.
Similar Series Models
- IS400TCASH1AGD: TCAS Core Analog Terminal Board (This item)
- IS400TCASH1A: TCAS Analog Terminal Board (older revision)
- IS400TDIH1AGD: Mark VIe Digital Input Terminal Board
- IS400TDOH1AGD: Mark VIe Digital Output Terminal Board
- IS400TPAH1AGD: Processor Companion Terminal Board
