GE M2LR-00-000-0 Moisture Probe

I. Product Basic Information
Brand Ownership: GE Panametrics (Precision Gas Humidity Measurement Division under GE)
Product Type: Alumina Dew Point / Moisture Probe
Model Status: Obsolete
Alternative Model: M2LR-00-010-0, fully compatible in function, only interface / casing slightly optimized
Origin: United States
Series Position: M2LR Universal Micro Water Analyzer Probe, compatible with all models of Panametrics Dew Point Hosts

Model Code Interpretation M2LR-XX-XX-XX
M2LR = Standard Alumina Humidity Probe
Section 1 – 00: Standard Insert Length
Section 2 – 00: No Built-in Temperature Sensor (Upgrade Model 010 has temperature measurement)
Section 3 – 00: Standard Electrical Connectors, No Explosion-proof Option

Core Technical Characteristics
Measurement Principle: Alumina Film Capacitance Method, Measuring Trace Moisture in Gases (Dew Point / ppmV)
Measurement Range: -110℃ ~ +20℃ Dew Point; ppb ~ ppm Level Trace Moisture
Explosion-proof Attribute: Explosion-proof Type, with Zener Safety Grid for use in petrochemical, natural gas explosion-proof areas
Advantages: Fast Response, Good Long-Term Calibration Stability, Low Drift
Compatible Equipment
GE Panametrics M Series, HygroPro, TransPort, OptiSonde Dew Point Analyzers
Typical Industries
Natural Gas, Air Separation, Semiconductor, Heat Treatment Furnace Gas, Electric Dry Air, Pharmaceutical Process Gas

Environment and Installation
Installation Method: Threaded Insertion, Direct Insertion into Process Pipelines / Sampling Tanks
Medium: Various Oil-Free, Liquid-Free Process Gases (Not Direct Contact with Liquid Water)
Working Temperature: -40℃ ~ +80℃ (Probe Body)
Pressure Tolerance: Maximum approximately 250 bar (Depends on Matching Connectors)

 Supply and Spare Parts Description
M2LR-00-000-0 is original factory brand new but out of stock. Only refurbished and second-hand inventory is available on the market.
When purchasing, prefer to choose the alternative M2LR-00-010-0, plug and play without program modification.
Companion Consumables: Probe Cable, Calibration Standard Gas, Replacement Alumina Sensor Core
