I. Basic Product Information
Brand: GE (Original Factory Curtiss-Wright Contract Manufacturing)
Model: PMC-0247RC-282000
Material Part Number: 350-93750247-282000F
Hardware Specifications: Standard PMC (PCI Submount) Industrial Embedded Processor Board Card, compatible with VME Industrial Control Enclosure, GE PACSystems Series Embedded Control System
Product Status: The original factory has discontinued production. The market circulation is mainly new inventory and disassembled industrial spare parts.
Model Interpretation
PMC: VITA Standard PCI Submount Expansion Card Specification
0247RC: Reinforced Industrial Hardware Version with Redundant Power Supply + Hardware Fault Detection
282000: Factory-Fixed Firmware Solidified Version Number
350-93750247-282000F: Whole Machine Material Traceability Code
Core Hardware Configuration
Main Control Processor
Freescale PowerPC 604e Industrial Processor, with a main frequency of 400 MHz, equipped with an embedded real-time processing core, specially designed for high-reliability industrial, military, and power scenarios.
Board-Specific Storage and Memory
Standard onboard memory: 128MB DDR SDRAM, which can be expanded up to 512MB
Onboard Flash Firmware Storage, solidifying system boot programs and driver firmware
Bus Interfaces
Standard PMC Gold Finger, based on PCI-X 133MHz Bus, connecting VME Main Control Backplane for high-speed data interaction
Posterior Multi-Path PMC Expansion Slots, which can be mounted with storage subcards, I/O Acquisition Subcards, and communication expansion cards
Debugging and Peripheral Interfaces
Onboard RS232 Serial Port, used for local firmware burning, system debugging, and fault log reading; reserved hardware watchdog circuit, automatically resetting in case of system crash to ensure 7×24-hour continuous operation.
Key Electrical & Environmental Parameters
Power Supply: DC 24V ± 15%, rated power consumption ≤ 16W, RC version comes with power surge, short circuit, and overvoltage redundant protection
Operating Temperature: Wide Temperature – 40℃ to +85℃, meeting vehicle-mounted, offshore platform, and high-temperature cabinet conditions of power plants
Protection Grade: IP20 (Rack Embedded Installation)
Shaking and Vibration Resistance: Compliant with MIL-STD military-level vibration and shock testing standards
Compatible Systems: VxWorks, Linux, Windows Embedded Industrial Real-time Operating Systems
Installation Method: Standard PMC Slot Embedded into VME64 Industrial Control Enclosure
Main Functional Characteristics
Embedded Real-time Computing Processing
As the processor of the industrial control system, responsible for high-speed collection of massive analog and digital quantities, logical preprocessing, motion control algorithm computing, and sharing the load of the main control CPU.
Industrial Data Local Storage
Can be expanded to 2.5-inch SATA Industrial SSD/HDD, storing control programs, SOE events, fault recording, and historical operation process data.
High-Reliability Hardware Redundancy Design
RC Redundancy Version integrates power monitoring, bus fault diagnosis, memory self-check, and automatically isolates and uploads fault alarms in case of hardware abnormalities, with single card failure not affecting the operation of the entire control system.
Multi-Device Expansion Capability
Onboard multi-path expansion slots, which can be flexibly expanded with I/O Acquisition Modules, Fiber Optic Communication Modules, and Storage Modules, suitable for distributed data acquisition and multi-axis synchronous motion control scenarios.
Typical Application Scenarios
Power Generation Units of Thermal Power, Hydropower, Nuclear Power, Excitation of DEH Steam Turbine Control System
VME Architecture DCS, SIS Safety Control System of Petrochemical Industry, Metallurgical Industry
Embedded Industrial Control Equipment for Ships, Rail Transit, Military Vehicles (Reinforced Type)
High-precision multi-axis synchronous motion control, industrial online data acquisition and recording system
