Product Description
Model MGate 5101‑PBM‑MN is an industrial protocol conversion gateway manufactured by MOXA. It is a 1‑port PROFIBUS‑DP V1 Master to Modbus‑TCP gatewayMoxa. Operating as PROFIBUS DP master, it connects PROFIBUS‑DP slave devices such as servo drives, instruments and PLCs, enabling bidirectional data exchange with Modbus‑TCP client/server hosts. Rugged metal housing for DIN‑rail mounting. Dual redundant DC power inputs and relay alarm output are provided. PROFIBUS serial port with built‑in 2 kV optical isolation; Ethernet port with 1.5 kV magnetic isolation. Configuration via MGate Manager utility or built‑in web console. Auto‑scan for PROFIBUS slaves, traffic diagnostic and fail‑safe functions are integrated. Standard model operates 0‑60℃; the‑T variant supports wide temperature‑40~+75℃. Suitable for factory automation, power, oil‑gas process automation, new system integration and legacy equipment spare‑part replacementMoxa Inc..
Key Specifications
| Item | Specification |
|---|---|
| Part Number | MGate 5101‑PBM‑MN |
| Manufacturer | MOXA |
| Function | PROFIBUS‑DP V1 Master to Modbus‑TCP protocol gateway |
| PROFIBUS Port | DB9 female, DP‑V1 Master; Baud rate 9.6k‑12 Mbps; 2 kV optical isolation |
| Ethernet Port | 1 × RJ45,10/100 Mbps Auto‑MDI/MDI‑X; 1.5 kV magnetic isolation |
| Modbus Mode | Modbus‑TCP Client / Server |
| Configuration | MGate Manager Windows utility, Web(HTTP/HTTPS), Telnet/SSH, RS232 serial console |
| Power Supply | 12‑48 VDC, dual redundant inputs; Max.4.3 W power consumption |
| Alarm Output | 1 relay output, 30 VDC / 2 A for fault alarm |
| Mounting | DIN‑rail mounting |
| Enclosure | Metal housing, IP30 |
| Dimensions(W×H×D) | 36 mm ×105 mm ×140 mm |
| Weight | Approx.500 g |
| Operating Temp.(Standard) | 0℃ ~ +60℃; Wide‑temp‑T variant:‑40℃ ~ +75℃ |
| Humidity | 5‑95 %RH non‑condensing |
| LED Indicators | PWR, Ready, Fault, PROFIBUS, LAN status LEDs |
| Certifications | CE, FCC;‑T version: ATEX / IECEx certified |
| Features | Auto‑scan PROFIBUS slaves, web‑based I/O visualization, traffic monitoring, fail‑safe, RTC real‑time clock |
Applications
- Factory automation: interconnect PROFIBUS‑DP servos / instruments with Modbus‑TCP PLC & SCADA systems
- Power industry: protocol conversion for generator sets and substation monitoring
- Oil‑gas, water treatment process‑automation field‑device networking
- Legacy‑system retrofitting: integrate old PROFIBUS equipment to modern industrial Ethernet controls
- Maintenance spare‑parts; migration of PROFIBUS field devices to Ethernet‑based architecture.
