MTL 8604-FT-FU Field Terminal Block

MTL 8604-FT-FU (Eaton MTL 8000 FieldTerm+ with fuse terminal base)
I. Basic Product Positioning
Brand: MTL (British brand of Eaton’s explosion-proof safety instrument), belonging to the 8000 series FieldTerm + bus I/O companion terminal base
Model Interpretation
8604: Compatible with 8000 series multi-channel analog acquisition / bus receiving mainboard
FT = Field Terminal – On-site wiring terminal base
FU = Fused – Independent fuse protection for each channel
Core Function: Hazardous area on-site instrument cable convergence, fuse overcurrent protection, signal transfer; Combined with 8000 series multi-channel multiplex receiving card, build an intrinsically safe explosion-proof distributed acquisition system
Explosion-proof Class: Ex ia IIC – Intrinsically safe explosion-proof, can be directly installed in Zone 0/1/2 flammable and explosive working conditions

Hardware Structure and Channel Protection
1. Wiring and Plug-in Structure
Upper cage-type spring screw terminals: Connect to on-site 4–20mA transmitters, temperature probes, and switch quantity instrument cables
Middle double-row sockets: Plug into 8000 series main control acquisition board cards (such as multi-channel analog multiplexing receiving module)
Each channel is equipped with a replaceable miniature fuse (standard 250mA), which melts independently in case of short circuit / overcurrent, preventing the entire channel from being paralyzed
2. Bus Communication Supporting Capacity
Supports dual redundant RS485 Modbus data highways (Data Highway), with a maximum speed of 19.2 kbit/s
One pair of twisted wires can transmit up to 32 analog acquisition signals, with a maximum transmission distance of 500 meters, significantly reducing the number of cables passing through the cabin
Input noise suppression: Peak 0.5mA from 100–1000Hz, highly resistant to inverter and motor electromagnetic interference
IIIElectrical Key Parameters Table
Parameter Item Specification Value
System Power Supply 24VDC, total system current consumption 100mA
Channel Isolation Voltage Rating 1500VAC reinforced isolation between input/output/power supply
Signal Standard 4–20mA two-wire transmitter loop power supply
Output Load Capacity Maximum 600Ω load resistance on the control system side
Measurement Accuracy Matching Compared with the mainboard, the typical ±0.1% FS range error of the entire system
Fuse Specifications Each channel comes with a standard 250mA slow-blow fuse, which can be replaced on-site
Installation Method Standard 35mm DIN rail snap-in installation
