NOTIFIER XP6-R C-type Relay Control Module

Product Description

NOTIFIER XP6-R (Honeywell Notifier) is a 6-channel addressable Form-C relay control module, an SLC loop device for FlashScan / CLIP intelligent fire alarm systems. It integrates 6 independent Form-C dry contact relays, each configurable for normally open or normally closed. The primary address is set via rotary switches, and the remaining 5 channels are assigned automatically. Up to 3 unused channels can be disabled to free addresses. Equipped with individual channel status LED indicators and removable pluggable terminals for easy wiring and maintenance. It outputs discrete signals for fire alarm systems; load circuit supervision is NOT supported.

Specifications

• Model: XP6-R
• Product Type: 6-Channel Addressable Form-C Relay Output Module
• Bus Protocol: FlashScan® / CLIP, SLC Signal Line Circuit
• Relay Type: Form-C dry contact (NO/NC/COM)
• Contact Rating: 30V DC, 70.7V AC
• Operating Voltage: 15～32V DC
• Standby Current: 1.45 mA
• Alarm Current: 32 mA (6 relays activated + all LEDs steady on)
• Addressing: Primary address 01～154, auto-assignment for other 5 channels; up to 3 unused channels can be disabled
• Terminals: Removable pluggable terminals, 12AWG～18AWG (0.9~3.25mm²)
• Mounting: CHS-6 chassis, BB-XP / CAB-3 / BB-25 enclosures
• Dimensions: H 172.72mm × W 147.32mm × D 31.75mm
• Operating Ambient Temperature: 0℃～49℃
• Relative Humidity: 10%～93%, non-condensing
• Certifications: UL, FM, CSFM

Application

This module connects to the SLC loop of Notifier intelligent fire alarm control panels. It provides passive dry-contact outputs upon fire alarm or logic activation. It is used to control smoke exhaust fans, fire dampers, audible/visual alarms, sprinkler pumps, elevator shutdown, door access release and other fire safety equipment. Widely deployed in commercial complexes, office buildings, hospitals, data centers and industrial plants.

Similar Series Models

XP6-C (6-channel supervised control module), XP6-MA (6-zone interface module), XP10-M (10-channel monitor module), XP8-M, XP4-M
