Product Description
Model: ND32‑5610VS‑101‑011‑00 Brand: NOVOTRON (Germany) Product Name: ND32 Series Servo Drive (Servo‑Converter)
ND32‑5610VS‑101‑011‑00 is a 19‑inch plug‑in servo drive module from German NOVOTRON NOVODRIVE family. It operates on 3‑phase 400V high‑voltage power supply with full‑digital vector control, suitable for synchronous servo motors and linear motors. It supports position, speed and torque control modes, compatible with multiple encoder feedback types, integrated multi‑axis fieldbus interface, configurable via NVStudio software. 19” rack plug‑in mechanical structure. OEM end‑of‑life, mainly supplied as used / refurbished spare parts for legacy‑machine repair.
Technical Specifications
| Item | Specifications |
|---|---|
| Model | ND32‑5610VS‑101‑011‑00 |
| Series | NOVODRIVE ND32 |
| Mounting | 19‑inch rack plug‑in module |
| Main Power Input | 3‑phase 380‑480V AC, 50/60Hz |
| DC‑link Voltage | 560 VDC |
| Rated Power | 5 kW |
| Control Modes | Position / Speed / Torque control |
| Compatible Motors | AC synchronous servo motors, linear motors |
| Feedback | Incremental encoder, absolute encoder, resolver |
| Communication | RS232, RS485, CAN bus, multi‑axis sync bus |
| Configuration Software | NVStudio |
| Protection | Over‑current, over‑voltage, under‑voltage, over‑temperature, short‑circuit protection |
| Operating Temperature | -10℃ ~ +50℃ |
| Storage Temperature | -40℃ ~ +70℃ |
| Product Status | OEM obsolete, spare‑part market supply |
| Weight | Approx.2.1 kg |
Product Application
- Servo axis driving for CNC machine tools and machining centers.
- Multi‑axis synchronous motion control for packaging & printing machinery.
- Precision positioning drive for industrial robots and automatic production lines.
- Retrofit, spare‑part replacement & maintenance for imported legacy automation equipment.
Main Series Part Numbers
- ND32‑5610VS‑001‑000‑00 5kW basic servo drive
- ND32‑5610VS‑101‑011‑31 5kW extended‑function variant
- ND32‑5100VS‑xxxx‑xx‑xx ND32 2.5 kW servo drive
- ND32‑5200VS‑xxxx‑xx‑xx ND32 10 kW servo drive
- ND31‑3202VS‑xxxx‑xx‑xx ND31 series,230V,0.5 kW
- ND31‑3204VS‑xxxx‑xx‑xx ND31 series,230V,1 kW
- ND31‑3207VS‑xxxx‑xx‑xx ND31 series,230V,2 kW
- ND31‑3212VS‑xxxx‑xx‑xx ND31 series,230V,4 kW
