Rexroth R151354013 is a type of ball screw produced by Bosch Rexroth. The following is a detailed introduction of this product:
I. Product Characteristics
Brand and Manufacturer:
Brand: Rexroth (Bosch Rexroth)
Manufacturer: Bosch Rexroth Company, a well-known industrial technology enterprise in Germany, specializing in drive and control technologies.
Model and Specifications:
Model: R151354013
Type: Ball Screw Nut, a core component of ball screw pairs, used to convert rotational motion into linear motion.
Applicable Media and Environment:
Applicable Media: Oil products (such as hydraulic oil, lubricating oil), need to be kept clean to avoid wear.
Pressure Environment: Normal pressure or high pressure (depending on the application scenario, such as machine tools, automation equipment, etc.).
Media Temperature: Usually -20℃ to 100℃, need to avoid extreme temperature affecting material performance.
Drive Method and Application:
Drive Method: Motor drive (through the ball screw pair to achieve high-precision linear motion).
Application: Widely used in machine tools, automation equipment, robots, precision transmission systems, etc., as a key transmission component.
Technical Parameters (Example)
Overall Dimensions: Depending on the specific design, it may include parameters such as the outer diameter, inner diameter, and length of the nut (refer to the product manual for details).
Pitch and Accuracy: Pitch (lead) affects the transmission speed and resolution, and accuracy grades (such as C5, C7) determine the positioning repeatability.
Load Capacity: Dynamic/static load rating, select the appropriate specification based on the application scenario.
Application Scenarios
Machine Tool Industry:
Used in the feed system of CNC machine tools to achieve high-precision and high-speed cutting motion.
Example: Z-axis/X-axis drive of milling machines, lathes, machining centers.
Automation Equipment:
Used in robot joints, linear modules, 3D printers, etc., to achieve precise positioning and motion control.
Example: End effector drive of Delta robots, SCARA robots.
Precision Transmission System:
Used in optical equipment, semiconductor manufacturing equipment, etc., requiring micrometer-level accuracy scenarios.
Example: Focusing system of wafer inspection machines, laser cutting machines.
